	xDrive35i	xDrive50i	X6 M	xDrive30d	xDrive40d	X6 M50d
Date of sale	-	-	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	6/24	8/32	8/32	6/24	6/24	6/24
Engine displacement [cm³]	2979	4395	4395	2993	2993	2993
Maximum output / speed [kW/min-1]	225/5800-6400	330/5500-6000	423/6000-6500	190/4000	230/4400	280/4000-4400
Maximum torque [Nm/min-1]	400/1200-5000	650/2000-4500	750/2200-5000	560/1500-3000	630/1500-2500	740/2000-3000
Bore and stroke [mm x mm]	84,0 x 89,6	89,0 x 88,3	89,0 x 88,3	84,0 x 90,0	84,0 x 90,0	84,0 x 90,0
Compression ratio	10,2:1	10,0:1	10,0:1	16,5:1	16,5:1	16,0:1
Oil volume [l]	6.5	9.0	9.5	6.5	6.5	6.5
Coolant volume [l]	10.3	14.9	16.8	12.6	12.6	15.4
Technical specifications	direct injection High Precision Injection turbo-supercharged Twin‐scroll variable timing of intake and exhaust valves Double‐VANOS variable lift of intake valves Valvetronic start&stop system brake energy recuperation	direct injection High Precision Injection supercharging by twin turbochargers variable timing of intake and exhaust valves Double‐VANOS variable lift of intake valves Valvetronic start&stop system brake energy recuperation	direct injection High Precision Injection supercharging by twin turbochargers TwinScroll variable timing of intake and exhaust valves Double‐VANOS variable lift of intake valves Valvetronic start&stop system brake energy recuperation	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter BluePerformance with AdBlue additive injection start&stop system brake energy recuperation	direct injection Common Rail supercharging by twin turbochargers (large and small, the small one with variable blade geometry) particulate filter SCR catalytic converter BluePerformance with AdBlue additive injection start&stop system brake energy recuperation	direct injection Common Rail supercharging by three turbochargers with variable blade geometry (two high-pressure and one low-pressure) particulate filter SCR catalytic converter BluePerformance with AdBlue additive injection start&stop system brake energy recuperation

Drive axle	4x4	4x4	4x4	4x4	4x4	4x4
Gearbox	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic	8 gear automatic
Drive specifications	all-wheel drive xDrive automatic gearbox Steptronic	all-wheel drive xDrive automatic gearbox Steptronic	all-wheel drive xDrive automatic gearbox Steptronic	all-wheel drive xDrive automatic gearbox Steptronic	all-wheel drive xDrive automatic gearbox Steptronic	all-wheel drive xDrive automatic gearbox Steptronic

Top speed [km/h]	240	250	250	230	240	250
Acceleration 0–100 km/h [s]	6.4	4.8	4.2	6.7	5.8	5.2
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	11.3-11.4	13.0-13.1	14.7	10.3-6.8	7.9-7.1	8.7-7.2
Out of town [l]	6.9-7.0	7.7-7.8	9.0	6.2-5.2	6.4-5.8	7.3-6.3
Combined [l]	8.5-8.6	9.7	11.1	7.1-6.0	7.0-6.3	7.8-6.6
CO2 emissions [g/km]	198-200	225-227	258	187-159	183-165	209-174

Emission standard	EU6	EU6	EU6	EU6 - EU6c	EU6 - EU6c	EU6 - EU6c
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	2100	2245	2340	2140	2180	2260
Overall weight [kg]	2740	2885	2950	2780	2820	2900
Maximum trailer weight unbraked/braked [kg]	750/2700 [750/3500 subject to a surcharge]	750/2700 [750/3500 subject to a surcharge]	750/2970	750/2700 [750/3500 subject to a surcharge]	750/2700 [750/3500 subject to a surcharge]	750/2700 [750/3500 subject to a surcharge]
Maximum front/rear axle load [kg]	1290 / 1530	1385 / 1570	1420/1610	1330 / 1540	1350 / 1550	1400 / 1570
Maximum vertical load on the tow bar [kg]	140	140	140	140	140	140
Maximum load on roof/carrier [kg]	100/-	100/-	100/-	100/-	100/-	100/-

Boot volume [l]	580	580	580	580	580	580
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1525	-/1525	-/1525	-/1525	-/1525	-/1525
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	85	85	85	85	85	85
AdBlue tank volume [l]	-	-	-	13.4	13.4	13.4
Air resistance [Cd]	0.34	0.35	0.37	0.32	0.32	0.36
Front suspension	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone
Rear suspension	Integral rear axle	Integral rear axle	Integral rear axle	Integral rear axle	Integral rear axle	Integral rear axle
Tyre dimensions front	255/50 R19 107W	255/50 R19 107W	285/40 R20 104Y	255/50 R19 107W	255/50 R19 107W	255/50 R19 107W
Tyre dimensions rear	255/50 R19 107W	255/50 R19 107W	325/35 R20 108Y	255/50 R19 107W	255/50 R19 107W	285/45 R19 111W
Wheel size front	9J x 19	9J x 19	10J x 20	9J x 19	9J x 19	9J x 19
Wheel size rear	9J x 19	9J x 19	11.5J x 20	9J x 19	9J x 19	10J x 19
Brake dimensions front	332 x 30	385 x 36	-	332 x 30	332 x 30	385 x 36
Brake dimensions rear	320 x 20	345 x 24	-	320 x 20	320 x 20	345 x 24
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	-/12.8	-/12.8	-/12.8	-/12.8	-/12.8	-/12.8

Overall length [mm]	4909	4909	4909	4909	4909	4909
Overall width without/including mirrors [mm]	1989/2170	1989/2170	1989/2170	1989/2170	1989/2170	1989/2170
Overall height [mm]	1702	1702	1702	1702	1702	1702
Wheelbase [mm]	2933	2933	2933	2933	2933	2933
Front wheel track [mm]	1640	1640	1640	1640	1640	1640
Rear wheel track [mm]	1706	1706	1706	1706	1706	1700
Forward overhang [mm]	890	890	-	890	890	890
Rear overhang [mm]	1086	1086	-	1086	1086	1086
Clearance [mm]	212	212	195	212	212	212
Wading depth [mm]	500	500	-	500	500	500
Approach angle front [°]	25	25	-	25	25	25
Approach angle rear [°]	22.5	22.5	-	22.5	22.5	22.5
Transition angle [°]	20	20	-	20	20	20
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	1013	1013	1013	1013	1013	1013
Headroom rear [mm]	962	962	962	962	962	962
Front elbow/shoulder width [mm]	1562/-	1562/-	1562/-	1562/-	1562/-	1562/-
Rear elbow/shoulder width [mm]	1514/-	1514/-	1514/-	1514/-	1514/-	1514/-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
