BMW X6
Date of manufacture
5/2008 – 2012 (SUV)
Platform
-
Manufacturing locations
Greer, South Carolina, USA
Kaliningrad, Russia
Designer
Pierre Leclercq
Tags
Large SUV
German cars
The BMW X6 is an SUV that has been produced since 2008. The vehicle is available in petrol, diesel or hybrid engine variants. The most powerful model is the X6 M with 408 kW of power and the fastest version is the X6 M with a top speed of 250 km/h. The most fuel-efficient model, the xDrive30d, has a fuel consumption of 7.4 l/100 km and emissions of 195 g/km. The luggage compartment volume is 570 l. The vehicle is manufactured in the United States and Russia.
Technical data
SUV
| xDrive35i | xDrive35i | xDrive50i | xDrive50i | X6 M | ActiveHybrid X6 E72 | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | from 2009 to | from 2009 to 2010 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Petrol supercharged + Electric |
| Number of cylinders/valves | 6/24 | 6/24 | 8/32 | 8/32 | 8/32 | 8/32 |
| Engine displacement [cm³] | 2979 | 2979 | 4395 | 4395 | 4395 | 4395 |
| Maximum output / speed [kW/min-1] | 225/5800-6250 | 225/5800 | 300/5500-6400 | 300/5500-6400 | 408/6000 | 300/5500-6400 67 el. 63 el. 357 total |
| Maximum torque [Nm/min-1] | 400/1300-5000 | 400/1200-5000 | 600/1750-4500 | 600/1750-4500 | 680/1500-5650 | 600/1750-4500 260 el. 280 el. 780 total |
| Bore and stroke [mm x mm] | 84,0 x 89,6 | 84,0 x 89,6 | 89,0 x 88,3 | 89,0 x 88,3 | 89,0 x 88,3 | 89,0 x 88,3 |
| Compression ratio | 10,2:1 | 10,2:1 | 10,0:1 | 10,0:1 | 9,3:1 | 10,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 6 gear automatic | 8 gear automatic | 6 gear automatic | 8 gear automatic | 6 gear automatic | 7 gear automatic |
| Drive specifications |
|
|
|
|
|
|
| Top speed [km/h] | 240 | 240 | 250 | 240 | 250 | 236 |
| Acceleration 0–100 km/h [s] | 6.7 | 6.7 | 5.4 | 5.4 | 4.7 | 5.6 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 14.9 | 13.2 | 17.7 | 17.5 | 19.3 | 10.8 |
| Out of town [l] | 8.9 | 8.3 | 9.9 | 9.6 | 10.8 | 9.4 |
| Combined [l] | 11.1 | 10.1 | 12.8 | 12.5 | 13.9 | 9.9 |
| CO2 emissions [g/km] | 259 | 236 | 299 | 292 | 325 | 231 |
| Emission standard | EU4/EU5 | EU5 | EU4/EU5 | EU5 | EU5 | EU5 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| System voltage [V] | - | - | - | - | - | - |
| Battery type and capacity | - | - | - | - | - | Nickel metal hydride, 2.4 kWh |
| Range with fully charged battery [km] | - | - | - | - | - | - |
| Charging time | - | - | - | - | - | - |
| Number of modules/cells | - | - | - | - | - | - |
| Battery weight [kg] | - | - | - | - | - | - |
| Charger | - | - | - | - | - | - |
| Standby weight [kg] | 2145 | 2145 | 2265 | 2265 | 2380 | 2525 |
| Overall weight [kg] | 2670 | 2670 | 2840 | 2790 | 2905 | 3025 |
| Maximum trailer weight unbraked/braked [kg] | 750/2700 | 750/2700 | 750/2700 | 750/2700 | 750/3000 | 750/2000 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 570 | 570 | 570 | 570 | 570 | 470 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1450 | -/1450 | -/1450 | -/1450 | -/1450 | -/1350 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 4-5 | 4-5 | 4-5 | 4-5 | 4-5 | 4-5 |
| Fuel tank volume [l] | 85 | 85 | 85 | 85 | 85 | 85 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.34 | 0.34 | 0.36 | 0.36 | 0.38 | 0.36 |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 255/50 R19 107V | 255/50 R19 107V | 255/50 R19 107V | 255/50 R19 107V | 275/40 R20 106Y | 255/50 R19 107V |
| Tyre dimensions rear | 255/50 R19 107V | 255/50 R19 107V | 255/50 R19 107V | 255/50 R19 107V | 315/35 R20 110Y | 255/50 R19 107V |
| Wheel size front | 9J x 19 | 9J x 19 | 9J x 19 | 9J x 19 | 10J x 20 | 9J x 19 |
| Wheel size rear | 9J x 19 | 9J x 19 | 9J x 19 | 9J x 19 | 11J x 20 | 9J x 19 |
| Brake dimensions front | 348 x 30 | 348 x 30 | 348 x 30 | 385 x 36 | 395 x 36 | 385 x 36 |
| Brake dimensions rear | 345 x 24 | 320 x 20 | 345 x 24 | 345 x 24 | 385 x 24 | 345 x 24 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | -/12.8 | -/12.8 | -/12.8 | -/12.8 | -/12.8 | -/12.8 |
| Overall length [mm] | 4877 | 4877 | 4877 | 4877 | 4876 | 4877 |
| Overall width without/including mirrors [mm] | 1983/- | 1983/- | 1983/- | 1983/- | 1983/- | 1983/- |
| Overall height [mm] | 1690 | 1690 | 1690 | 1690 | 1684 | 1697 |
| Wheelbase [mm] | 2933 | 2933 | 2933 | 2933 | 2933 | 2933 |
| Front wheel track [mm] | 1644 | 1644 | 1644 | 1644 | 1660 | 1644 |
| Rear wheel track [mm] | 1706 | 1706 | 1706 | 1706 | 1672 | 1706 |
| Forward overhang [mm] | 858 | 858 | 858 | 858 | 856 | 858 |
| Rear overhang [mm] | 1086 | 1086 | 1086 | 1086 | 1087 | 1086 |
| Clearance [mm] | 212 | 212 | 212 | 212 | 205 | 219 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | 25.1 | 25.1 | 25.1 | 25.1 | 22 | 26.1 |
| Approach angle rear [°] | 25.5 | 25.5 | 25.5 | 25.5 | 21.5 | 25.9 |
| Transition angle [°] | 19.1 | 19.1 | 19.1 | 19.1 | 18.6 | 19.7 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 973 | 973 | 973 | 973 | 973 | 973 |
| Headroom rear [mm] | 946 | 946 | 946 | 946 | 946 | 946 |
| Front elbow/shoulder width [mm] | 1551/- | 1551/- | 1551/- | 1551/- | 1521/- | 1551/- |
| Rear elbow/shoulder width [mm] | 1513/- | 1513/- | 1513/- | 1513/- | 1448/- | 1513/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| xDrive30d | xDrive30d | xDrive35d | xDrive40d | |||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | ||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | ||
| Number of cylinders/valves | 6/24 | 6/24 | 6/24 | 6/24 | ||
| Engine displacement [cm³] | 2993 | 2993 | 2993 | 2993 | ||
| Maximum output / speed [kW/min-1] | 173/4000 | 180/4000 | 210/4400 | 225/4400 | ||
| Maximum torque [Nm/min-1] | 520/2000-2750 | 540/1750-3000 | 580/1750-2250 | 600/1500-2500 | ||
| Bore and stroke [mm x mm] | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | ||
| Compression ratio | 17,0:1 | 16,5:1 | 17,0:1 | 16,5:1 | ||
| Oil volume [l] | - | - | - | - | ||
| Coolant volume [l] | - | - | - | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | ||
| Gearbox | 6 gear automatic | 8 gear automatic | 6 gear automatic | 8 gear automatic | ||
| Drive specifications |
|
|
|
| ||
| Top speed [km/h] | 210 | 210 | 236 | 236 | ||
| Acceleration 0–100 km/h [s] | 8.0 | 7.5 | 6.9 | 6.5 | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | - | - | - | - | ||
| City [l] | 10.4 | 8.7 | 10.5 | 8.8 | ||
| Out of town [l] | 7.0 | 6.7 | 7.1 | 6.8 | ||
| Combined [l] | 8.2 | 7.4 | 8.3 | 7.5 | ||
| CO2 emissions [g/km] | 217 | 195 | 220 | 198 | ||
| Emission standard | EU4 | EU5 | EU4 | EU5 | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | - | - | - | - | ||
| Driving noise [dB] | - | - | - | - | ||
| Standby weight [kg] | 2150 | 2150 | 2185 | 2185 | ||
| Overall weight [kg] | 2675 | 2675 | 2710 | 2710 | ||
| Maximum trailer weight unbraked/braked [kg] | 750/2700 | 750/2700 | 750/2700 | 750/2700 | ||
| Maximum front/rear axle load [kg] | - | - | - | - | ||
| Maximum vertical load on the tow bar [kg] | - | - | - | - | ||
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | ||
| Boot volume [l] | 570 | 570 | 570 | 570 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1450 | -/1450 | -/1450 | -/1450 | ||
| Boot length [mm] | - | - | - | - | ||
| Boot length with rear seats folded [mm] | - | - | - | - | ||
| Boot width between wheels/max [mm] | - | - | - | - | ||
| Boot height to headliner/ceiling [mm] | - | - | - | - | ||
| Loading edge height [mm] | - | - | - | - | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | - | - | - | - | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 5 | 5 | 5 | 5 | ||
| Number of seats | 4-5 | 4-5 | 4-5 | 4-5 | ||
| Fuel tank volume [l] | 85 | 85 | 85 | 85 | ||
| AdBlue tank volume [l] | - | - | - | - | ||
| Air resistance [Cd] | 0.33 | 0.33 | 0.34 | 0.34 | ||
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | ||
| Rear suspension | multilink | multilink | multilink | multilink | ||
| Tyre dimensions front | 255/50 R19 107V | 255/50 R19 107V | 255/50 R19 107V | 255/50 R19 107V | ||
| Tyre dimensions rear | 255/50 R19 107V | 255/50 R19 107V | 255/50 R19 107V | 255/50 R19 107V | ||
| Wheel size front | 9J x 19 | 9J x 19 | 9J x 19 | 9J x 19 | ||
| Wheel size rear | 9J x 19 | 9J x 19 | 9J x 19 | 9J x 19 | ||
| Brake dimensions front | 348 x 30 | 332 x 30 | 365 x 36 | 348 x 30 | ||
| Brake dimensions rear | 320 x 20 | 320 x 20 | 345 x 24 | 320 x 20 | ||
| Steering | - | - | - | - | ||
| Number of steering wheel turns | - | - | - | - | ||
| Turning diameter track/circumference [m] | 12.8 | 12.8 | 12.8 | 12.8 | ||
| Overall length [mm] | 4877 | 4877 | 4877 | 4877 | ||
| Overall width without/including mirrors [mm] | 1983/- | 1983/- | 1983/- | 1983/- | ||
| Overall height [mm] | 1690 | 1690 | 1690 | 1690 | ||
| Wheelbase [mm] | 2933 | 2933 | 2933 | 2933 | ||
| Front wheel track [mm] | 1644 | 1644 | 1644 | 1644 | ||
| Rear wheel track [mm] | 1706 | 1706 | 1706 | 1706 | ||
| Forward overhang [mm] | 858 | 858 | 858 | 858 | ||
| Rear overhang [mm] | 1086 | 1086 | 1086 | 1086 | ||
| Clearance [mm] | 212 | 212 | 212 | 212 | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | 25.1 | 25.1 | 25.1 | 25.1 | ||
| Approach angle rear [°] | 25.5 | 25.5 | 25.5 | 25.5 | ||
| Transition angle [°] | 19.1 | 19.1 | 19.1 | 19.1 | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | 973 | 973 | 973 | 973 | ||
| Headroom rear [mm] | 946 | 946 | 946 | 946 | ||
| Front elbow/shoulder width [mm] | 1551/- | 1551/- | 1551/- | 1551/- | ||
| Rear elbow/shoulder width [mm] | 1513/- | 1513/- | 1513/- | 1513/- | ||
| Legroom front knees/total [mm] | - | - | - | - | ||
| Legroom rear knees/total [mm] | - | - | - | - |
