BMW X5
Date of manufacture
8/2013 – 2018 (SUV)
Platform
-
Manufacturing locations
Greer, South Carolina, USA
Kaliningrad, Russia
Designer
Mark Johnson
Tags
Sport SUV
German cars
The BMW X5 has been available as an SUV since 2013. The car is manufactured by the company in the USA and Russia. Petrol, diesel and hybrid engines are available, with the most powerful model being the X5 M F85 with a maximum power of 423 kW. The fastest model reaches a speed of 250 km/h, while the most economical X5 xDrive40e consumes 3.3 l/100 km and emits 77 g CO2/km. The luggage compartment has a capacity of 500 liters.
Car body style
SUV
Date of manufacture
8/2013 – 2018Internal designation
F15Engine size
Technical data
SUV
| X5 xDrive35i | X5 xDrive50i | X5 M F85 | X5 xDrive40e | X5 sDrive25d | X5 xDrive25d | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | from 1/2015 to | from 3/2015 to | from to 5/2015 | from to 5/2015 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Petrol supercharged + Electric | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 6/24 | 8/32 | 8/32 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 2979 | 4395 | 4395 | 1997 | 1995 | 1995 |
| Maximum output / speed [kW/min-1] | 225/5800-6400 | 330/5500-6000 | 423/6000-6500 | 180/5000 -6500 83/3170 el. 230 total | 160/4400 | 160/4400 |
| Maximum torque [Nm/min-1] | 400/1200-5000 | 650/2000-4500 | 750/2200-5000 | 350/1250-4800 250/0 el. | 450/1500-2500 | 450/1500-2500 |
| Bore and stroke [mm x mm] | 84,0 x 89,6 | 89,0 x 88,3 | 89,0 x 88,3 | 84.0 x 90.1 | 84,0 x 90,0 | 84,0 x 90,0 |
| Compression ratio | 10,2:1 | 10,0:1 | 10,0:1 | 10.0:1 | 16,5:1 | 16,5:1 |
| Oil volume [l] | 6.5 | 9.0 | 9.5 | 5.0 | 5.2 | 5.2 |
| Coolant volume [l] | 10.3 | 14.7 | 16.8 | - | 12.6 | 12.6 |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | - | Rear | 4x4 |
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | - | 8 gear automatic | 8 gear automatic |
| Drive specifications |
|
|
| - |
|
|
| Top speed [km/h] | 235 | 250 | 250 | 210 [120 el.] | 220 | 220 |
| Acceleration 0–100 km/h [s] | 6.5 | 4.9 | 4.2 | 6.8 | 8.2 | 8.2 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 11.2-11.3 | 12.9-13.0 | 14.7 | - | 6.5-6.6 | 6.7-6.8 |
| Out of town [l] | 6.9 | 7.7-7.8 | 9.0 | - | 5.2 | 5.3-5.4 |
| Combined [l] | 8.5 | 9.6-9.7 | 11.1 | 3.4-3.3 [15.4-15.3 kWh] | 5.6-5.7 | 5.8-5.9 |
| CO2 emissions [g/km] | 197-199 | 224-226 | 258 | 78-77 | 149-151 | 154-156 |
| Emission standard | EU6 | EU6 | EU6 | EU6 | EU6 | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| System voltage [V] | - | - | - | 351 | - | - |
| Battery type and capacity | - | - | - | Lithium-ion, 9.2 kWh (6.8 net) | - | - |
| Range with fully charged battery [km] | - | - | - | 31 | - | - |
| Charging time | - | - | - |
| - | - |
| Number of modules/cells | - | - | - | -/96 | - | - |
| Battery weight [kg] | - | - | - | - | - | - |
| Charger | - | - | - | - | - | - |
| Standby weight [kg] | 2105 | 2250 | 2350 | 2305 | 2070 | 2115 |
| Overall weight [kg] | 2745 | 2890 | 2970 | 2980 | 2070 | 2755 |
| Maximum trailer weight unbraked/braked [kg] | 750/2700 [750/3500 subject to a surcharge] | 750/2700 [750/3500 subject to a surcharge] | 750/2970 | 750/2700 | 750/2700 | 750/2700 |
| Maximum front/rear axle load [kg] | 1280 / 1540 | 1375 / 1585 | 1420/1630 | 1250/1755 | 1220 / 1525 | 1265 / 1530 |
| Maximum vertical load on the tow bar [kg] | 140 | 140 | 140 | 140 | 140 | 140 |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100 /- | 100/- | 100/- |
| Boot volume [l] | 650 | 650 | 650 | 500 | 650 | 650 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1870 | -/1870 | -/1870 | -/1720 | -/1870 | -/1870 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5-7 | 5-7 | 5-7 | 5 | 5-7 | 5-7 |
| Fuel tank volume [l] | 85 | 85 | 85 | 85 | 85 | 85 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.31 | 0.33 | 0.38 | 0.31 | 0.31 | 0.31 |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone |
| Rear suspension | Integral rear axle | Integral rear axle | Integral rear axle | Integral rear axle | Integral rear axle | Integral rear axle |
| Tyre dimensions front | 255/55 R18 109V | 255/50 R19 107W | 285/40 R20 104Y | 255/55 R18 109 V XL | 255/55 R18 109V | 255/55 R18 109V |
| Tyre dimensions rear | 255/55 R18 109V | 255/50 R19 107W | 325/35 R20 108Y | 255/55 R18 109 V XL | 255/55 R18 109V | 255/55 R18 109V |
| Wheel size front | 8.5J x 18 | 9J x 19 | 10J x 20 | 8.5J x 18 | 8.5J x 18 | 8.5J x 18 |
| Wheel size rear | 8.5J x 18 | 9J x 19 | 11.5J x 20 | 8.5J x 18 | 8.5J x 18 | 8.5J x 18 |
| Brake dimensions front | 332 x 30 | 385 x 36 | - | - | 332 x 30 | 332 x 30 |
| Brake dimensions rear | 320 x 20 | 345 x 24 | - | - | 320 x 20 | 320 x 20 |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | -/12.7 | -/12.7 | -/12.8 | 12.7/- | -/12.7 | -/12.7 |
| Overall length [mm] | 4886 | 4886 | 4880 | 4886 | 4886 | 4886 |
| Overall width without/including mirrors [mm] | 1938/2184 | 1938/2184 | 1985/- | 1938/2184 | 1938/2184 | 1938/2184 |
| Overall height [mm] | 1762 | 1762 | 1754 | 1762 | 1762 | 1762 |
| Wheelbase [mm] | 2933 | 2933 | 2933 | 2933 | 2933 | 2933 |
| Front wheel track [mm] | 1644 | 1644 | 1666 | 1644 | 1644 | 1644 |
| Rear wheel track [mm] | 1650 | 1650 | 1667 | 1650 | 1650 | 1650 |
| Forward overhang [mm] | 890 | 890 | - | 890 | 890 | 890 |
| Rear overhang [mm] | 1063 | 1063 | - | 1063 | 1063 | 1063 |
| Clearance [mm] | 209 | 209 | - | 209 | 209 | 209 |
| Wading depth [mm] | 500 | 500 | - | 500 | 500 | 500 |
| Approach angle front [°] | 25 | 25 | - | 25.0 | 25 | 25 |
| Approach angle rear [°] | 20 | 20 | - | 22.5 | 20 | 20 |
| Transition angle [°] | 20 | 20 | - | 20.0 | 20 | 20 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1029 | 1029 | 1029 | 1029 | 1029 | 1029 |
| Headroom rear [mm] | 985 | 985 | 985 | 985 | 985 | 985 |
| Front elbow/shoulder width [mm] | 1562/- | 1562/- | 1562/- | 1562/- | 1562/- | 1562/- |
| Rear elbow/shoulder width [mm] | 1525/- | 1525/- | 1525/- | 1525/- | 1525/- | 1525/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| X5 sDrive25d | X5 xDrive25d | X5 xDrive30d | X5 xDrive40d | X5 M50d | ||
|---|---|---|---|---|---|---|
| Date of sale | from 5/2015 to | from 5/2015 to | - | - | - | |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | |
| Number of cylinders/valves | 4/16 | 4/16 | 6/24 | 6/24 | 6/24 | |
| Engine displacement [cm³] | 1995 | 1995 | 2993 | 2993 | 2993 | |
| Maximum output / speed [kW/min-1] | 170/4400 | 170/4400 | 190/4000 | 230/4400 | 280/4000-4400 | |
| Maximum torque [Nm/min-1] | 500/1500-3000 | 500/1500-3000 | 560/1500-3000 | 630/1500-2500 | 740/2000-3000 | |
| Bore and stroke [mm x mm] | 84.0 x 90.0 | 84.0 x 90.0 | 84,0 x 90,0 | 84,0 x 90,0 | 84,0 x 90,0 | |
| Compression ratio | 16.5:1 | 16.5:1 | 16,5:1 | 16,5:1 | 16,0:1 | |
| Oil volume [l] | 5.0 | 5.0 | 6.5 | 6.5 | 6.5 | |
| Coolant volume [l] | - | - | 12.6 | 12.6 | 15.4 | |
| Technical specifications |
|
|
|
|
| |
| Drive axle | Rear | 4x4 | 4x4 | 4x4 | 4x4 | |
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | |
| Drive specifications |
|
|
|
|
| |
| Top speed [km/h] | 220 | 220 | 230 | 236 | 250 | |
| Acceleration 0–100 km/h [s] | 7.7 | 7.7 | 6.8 | 5.9 | 5.3 | |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | |
| City [l] | 5,9-5.9 | 6,2-6.2 | 7.8--6.8 | 7.8-6.8 | 8.7-7.2 | |
| Out of town [l] | 5.0-4,9 | 5.3-5,2 | 6.4-5.5 | 6.4-5.6 | 7.2-6.2 | |
| Combined [l] | 5.4-5,3 | 5.6-5,6 | 6.9-6.0 | 6.9-6.0 | 7.8-6.6 | |
| CO2 emissions [g/km] | 141-139 | 148-146 | 183-158 | 183-159 | 205-173 | |
| Emission standard | EU6 | EU6 | EU6 | EU6 | EU6 | |
| Standard for fuel consumption measurement | - | - | - | - | - | |
| Energy class | - | - | - | - | - | |
| Stationary vehicle noise [dB] | - | - | - | - | - | |
| Driving noise [dB] | - | - | - | - | - | |
| Standby weight [kg] | 2070 | 2115 | 2145 | 2185 | 2265 | |
| Overall weight [kg] | 2710 | 2755 | 2785 | 2825 | 2905 | |
| Maximum trailer weight unbraked/braked [kg] | 750/2700 | 750/2700 | 750/2700 [750/3500 subject to a surcharge] | 750/2700 | 750/2700 [750/3500 subject to a surcharge] | |
| Maximum front/rear axle load [kg] | 1210/ 1545 | 1250/ 1550 | 1320 / 1545 | 1340 / 1560 | 1370 / 1580 | |
| Maximum vertical load on the tow bar [kg] | 140 | 140 | 140 | 140 | 140 | |
| Maximum load on roof/carrier [kg] | 100 /- | 100 /- | 100/- | 100/- | 100/- | |
| Boot volume [l] | 650 | 650 | 650 | 650 | 650 | |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1870 | -/1870 | -/1870 | -/1870 | -/1870 | |
| Boot length [mm] | - | - | - | - | - | |
| Boot length with rear seats folded [mm] | - | - | - | - | - | |
| Boot width between wheels/max [mm] | - | - | - | - | - | |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | |
| Loading edge height [mm] | - | - | - | - | - | |
| Height of the open boot door [mm] | - | - | - | - | - | |
| Boot opening height [mm] | - | - | - | - | - | |
| Boot opening width min/max [mm] | - | - | - | - | - | |
| Number of doors | 5 | 5 | 5 | 5 | 5 | |
| Number of seats | 5-7 | 5-7 | 5-7 | 5-7 | 5-7 | |
| Fuel tank volume [l] | 85 | 85 | 85 | 85 | 85 | |
| AdBlue tank volume [l] | - | - | - | - | - | |
| Air resistance [Cd] | 0.31 | 0.31 | 0.31 | 0.31 | 0.35 | |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | |
| Rear suspension | Integral rear axle | Integral rear axle | Integral rear axle | Integral rear axle | Integral rear axle | |
| Tyre dimensions front | 255/55 R18 109 VXL | 255/55 R18 109 VXL | 255/55 R18 109V | 255/55 R18 109V | 255/50 R19 107W | |
| Tyre dimensions rear | 255/55 R18 109 VXL | 255/55 R18 109 VXL | 255/55 R18 109V | 255/55 R18 109V | 285/45 R19 111W | |
| Wheel size front | 8,5J x 18 | 8,5J x 18 | 8.5J x 18 | 8.5J x 18 | 9J x 19 | |
| Wheel size rear | 8,5J x 18 | 8,5J x 18 | 8.5J x 18 | 8.5J x 18 | 10J x 19 | |
| Brake dimensions front | - | - | 332 x 30 | 332 x 30 | 385 x 36 | |
| Brake dimensions rear | - | - | 320 x 20 | 320 x 20 | 345 x 24 | |
| Steering | - | - | - | - | - | |
| Number of steering wheel turns | - | - | - | - | - | |
| Turning diameter track/circumference [m] | 12.7/- | 12.7/- | -/12.7 | -/12.7 | -/12.7 | |
| Overall length [mm] | 4886 | 4886 | 4886 | 4886 | 4886 | |
| Overall width without/including mirrors [mm] | 1938/2184 | 1938/2184 | 1938/2184 | 1938/2184 | 1985/2184 | |
| Overall height [mm] | 1762 | 1762 | 1762 | 1762 | 1762 | |
| Wheelbase [mm] | 2933 | 2933 | 2933 | 2933 | 2933 | |
| Front wheel track [mm] | 1644 | 1644 | 1644 | 1644 | 1662 | |
| Rear wheel track [mm] | 1650 | 1650 | 1650 | 1650 | 1702 | |
| Forward overhang [mm] | 890 | 890 | 890 | 890 | 890 | |
| Rear overhang [mm] | 1063 | 1063 | 1063 | 1063 | 1063 | |
| Clearance [mm] | 209 | 209 | 209 | 209 | 209 | |
| Wading depth [mm] | 500 | 500 | 500 | 500 | 500 | |
| Approach angle front [°] | 25 | 25 | 25 | 25 | 25 | |
| Approach angle rear [°] | 20 | 20 | 20 | 20 | 20 | |
| Transition angle [°] | 20 | 20 | 20 | 20 | 20 | |
| Climbing rate [°] | - | - | - | - | - | |
| Maximum side tilt [°] | - | - | - | - | - | |
| Headroom front [mm] | 1029 | 1029 | 1029 | 1029 | 1029 | |
| Headroom rear [mm] | 985 | 985 | 985 | 985 | 985 | |
| Front elbow/shoulder width [mm] | 1562/- | 1562/- | 1562/- | 1562/- | 1562/- | |
| Rear elbow/shoulder width [mm] | 1525/- | 1525/- | 1525/- | 1525/- | 1525/- | |
| Legroom front knees/total [mm] | - | - | - | - | - | |
| Legroom rear knees/total [mm] | - | - | - | - | - |
