BMW X4
Date of manufacture
7/2018 – to this day (Medium SUV)
Platform
CLAR platform
Manufacturing locations
Greer, South Carolina, USA
Kaliningrad, Russia
Designer
-
Tags
Compact SUV
German cars
The BMW X4 is manufactured as a mid-size SUV. The vehicle has been in production since 2018. Countries of production for the vehicle include the USA and Russia. The vehicle is built on the CLAR platform. The list of power units includes petrol, diesel and hybrid engines. The maximum power (375 kW) is achieved by the X4 M F98 Competition. The highest speed of 250 km/h is achieved by the X4 M F98 Competition. The most fuel-efficient model is the X4 xDrive20d with a combined fuel consumption of 4.8 l/100 km and CO2 emissions of 125 g/km. The luggage compartment size is 525 l. The model was tested in the safety area in 2017 and achieved an overall rating of 5 out of 5 according to EURONCAP.
Car body style
Medium SUV
Date of manufacture
7/2018 – to this dayInternal designation
G02Engine size
Technical data
Medium SUV
| X4 xDrive20i | X4 xDrive30i | X4 M40i | X4 M F98 | X4 M F98 Competition | X4 xDrive20d | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | from to 2020 | from 4/2019 to | from 4/2019 to | from to 2/2020 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4 /16 | 6/24 | 6 /24 | 6 /24 | 4 /16 |
| Engine displacement [cm³] | 1998 | 1998 | 2998 | 2993 | 2993 | 1995 |
| Maximum output / speed [kW/min-1] | 135/5000-6500 | 185/5200 -6500 | 265/5500-6500 | 353/6250 | 375/6250 | 140/4000 |
| Maximum torque [Nm/min-1] | 290/1350-4250 | 350/1450-4800 | 500/1550-4500 | 600/2600-5600 | 600/2600-5950 | 400/1750-2500 |
| Bore and stroke [mm x mm] | 82.0 x 94.6 | 82.0 x 94.6 | 82.0 x 94.6 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 |
| Compression ratio | 11.0:1 | 10.2:1 | 11.0:1 | 9.3:1 | 9.3:1 | 16.5:1 |
| Oil volume [l] | 5.25 | 5.25 | 6.5 | 7.0 | 7.0 | 5.0 |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic |
| Drive specifications |
|
|
|
|
|
|
| Top speed [km/h] | 215 | 240 | 250 | 250/280 | 250/285 | 213 |
| Acceleration 0–100 km/h [s] | 8.3 | 6.3 | 4.8 | 4.22 | 4.12 | 8.0 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 8,8-8,5 | 8,5-8,4 | 11,5-9.8 | 13.7-12.9 | 13.5-12.8 | 6,3-5,9 |
| Out of town [l] | 6,5-6,3 | 6,7-6,4 | 7,7-6.6 | 9.0-8.6 | 9.0-8.7 | 5,3-5,1 |
| Combined [l] | 7,3-7,1 | 7,3-7,2 | 9,1-7.8 | 10.5 | 10.5 | 5,6-5,4 |
| CO2 emissions [g/km] | 168-163 | 168-164 | 206-177 | 239 | 239 | 149-142 |
| Emission standard | EU6 - EU6d-TEMP - EU6d | EU6 - EU6d-TEMP - EU6d | EU6 - EU6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP | EU6 - EU6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1795 | 1795 | 1900-1940 | 2045 | 2045 | 1815 |
| Overall weight [kg] | 2400 | 2400 | 2430-2530 | 2500 | 2500 | 2400 |
| Maximum trailer weight unbraked/braked [kg] | 750/2000-2400 | 750/2000-2400 | 750/2000 | 750/2400 | 750/2400 | 750/2000-2400 |
| Maximum front/rear axle load [kg] | 1135/1370 | 1135/1370 | 1190/ 1375 | 1185/1425 | 1185/1425 | 1160/1395 |
| Maximum vertical load on the tow bar [kg] | 100 | 100 | 100 | 100 | 100 | 100 |
| Maximum load on roof/carrier [kg] | 100 /- | 100 /- | 100/- | 100 /- | 100 /- | 100 /- |
| Boot volume [l] | 525 | 525 | 525 | 525 | 525 | 525 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1430 | -/1430 | -/1430 | -/1430 | -/1430 | -/1430 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 65 | 65 | 65 | 65 | 65 | 60-68 |
| AdBlue tank volume [l] | - | - | - | - | - | 20.5 |
| Air resistance [Cd] | 0.30 | 0.30 | 0.30 | 0.36 | 0.36 | 0.30 |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 225/60 R18 104W XL | 225/60 R18 104W XL | 245/45 R20 103W XL | 255/45 ZR20 105Y XL | 255/40 ZR21 102Y XL | 225/60 R18 104W XL |
| Tyre dimensions rear | 225/60 R18 104W XL | 225/60 R18 104W XL | 275/40 R20 106W XL | 265/45 ZR20 108Y XL | 265/40 ZR21 105Y XL | 225/60 R18 104W XL |
| Wheel size front | 7J x 18 | 7J x 18 | 8J x 20 | 9J x 20 | 9,5J x 21 | 7J x 18 |
| Wheel size rear | 7J x 18 | 7J x 18 | 9,5J x 20 | 10J x 20 | 10J x 21 | 7J x 18 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electro-mechanical power steering Servotronic | Electro-mechanical power steering Servotronic | Electro-mechanical power steering Servotronic | Electro-mechanical power steering Servotronic | Electro-mechanical power steering Servotronic | Electro-mechanical power steering Servotronic |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 12.1/- | 12.1/- | 12.1/- | 12.6/- | 12.6/- | 12.1/- |
| Overall length [mm] | 4752 | 4752 | 4733 | 4758 | 4758 | 4752 |
| Overall width without/including mirrors [mm] | 1918/2138 | 1918/2138 | 1938/- | 1927/- | 1927/- | 1918/2138 |
| Overall height [mm] | 1621 | 1621 | 1621 | 1618 | 1620 | 1621 |
| Wheelbase [mm] | 2864 | 2864 | 2864 | 2864 | 2864 | 2864 |
| Front wheel track [mm] | 1620 | 1620 | 1615 | 1623 | 1617 | 1620 |
| Rear wheel track [mm] | 1666 | 1666 | 1624 | 1632 | 1632 | 1666 |
| Forward overhang [mm] | 861 | 861 | 861 | 864 | 864 | 861 |
| Rear overhang [mm] | 1027 | 1027 | 1027 | 1030 | 1030 | 1027 |
| Clearance [mm] | 204 | 204 | 204 | - | - | 204 |
| Wading depth [mm] | 500 | 500 | 500 | - | - | 500 |
| Approach angle front [°] | 25,0 | 25,0 | 25,0 | - | - | 25,0 |
| Approach angle rear [°] | 21.9 | 21.9 | 21.9 | - | - | 21.9 |
| Transition angle [°] | 20.0 | 20.0 | 20.0 | - | - | 20.0 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1024 | 1024 | 1024 | 1024 | 1024 | 1024 |
| Headroom rear [mm] | 953 | 953 | 953 | 953 | 953 | 953 |
| Front elbow/shoulder width [mm] | 1522/- | 1522/- | 1522/- | 1522/- | 1522/- | 1522/- |
| Rear elbow/shoulder width [mm] | 1478/- | 1478/- | 1478/- | 1478/- | 1478/- | 1478/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| X4 xDrive25d | X4 xDrive30d | X4 M40d | X4 xDrive20d | X4 xDrive30d | X4 M40d | |
|---|---|---|---|---|---|---|
| Date of sale | from 4/2018 to 2019 | from to 8/2020 | from to 8/2020 | from 2/2020 to | from 8/2020 to | from 8/2020 to |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged + Electric | Diesel supercharged + Electric | Diesel supercharged + Electric |
| Number of cylinders/valves | 4 /16 | 6/24 | 6/24 | 4/16 | 6/24 | 6/24 |
| Engine displacement [cm³] | 1995 | 2993 | 2993 | 1995 | 2993 | 2993 |
| Maximum output / speed [kW/min-1] | 170/4400 | 195/4000 | 240/4400 | 140/4000 8 el. | 210/4000 8 el. | 250/4400 8 el. |
| Maximum torque [Nm/min-1] | 500/2000 | 620/2000-2500 | 680/1750-2750 | 400/1750-2500 | 650/1500-2500 | 700/1750-2250 |
| Bore and stroke [mm x mm] | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 |
| Compression ratio | 16.5:1 | 16.5:1 | 16.5:1 | 16.5:1 | 16.5:1 | 16.5:1 |
| Oil volume [l] | 5.0 | 5,0-6,5 | 6.5 | 5.5 | 7.0 | 7.0 |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic |
| Drive specifications |
|
|
|
|
|
|
| Top speed [km/h] | 230 | 240 | 250 | 213 | 245 | 250 |
| Acceleration 0–100 km/h [s] | 6.8 | 5.8 | 4.9 | 7.9 | 5.7 | 4.9 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 6,3-6,2 | 6,9-6,7 | 7,3-7,2 | 5.5-5.2 | 6.7-6.3 | 7.2-6.9 |
| Out of town [l] | 5,3-5,1 | 5,5-5,4 | 6,3-5,9 | 4.8-4.5 | 4.9-4.5 | 5.2-4.8 |
| Combined [l] | 5,7-5,5 | 6,0-5,8 | 6,6-6,4 | 5.1-4.8 | 5.6-5.1 | 5.9-5.6 |
| CO2 emissions [g/km] | 149-145 | 158-153 | 173-170 | 133-125 | 146-136 | 156-147 |
| Emission standard | EU6 - EU6d-TEMP EU6 | EU6 - EU6d-TEMP | EU6 - EU6d-TEMP | Euro 6d | Euro 6d | Euro 6d |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| System voltage [V] | - | - | - | 48 | 48 | 48 |
| Battery type and capacity | - | - | - | Lithium-Ionen-Akkumulator, 11 A⋅h | Lithium-Ionen-Akkumulator, 11 A⋅h | Lithium-Ionen-Akkumulator, 11 A⋅h |
| Range with fully charged battery [km] | - | - | - | - | - | - |
| Charging time | - | - | - | - | - | - |
| Number of modules/cells | - | - | - | - | - | - |
| Battery weight [kg] | - | - | - | - | - | - |
| Charger | - | - | - | - | - | - |
| Standby weight [kg] | 1830 | 1895 | 1970 | 1925 | 2005 | 2095 |
| Overall weight [kg] | 2420 | 2460 | 2525 | 2585 | 2530 | 2555 |
| Maximum trailer weight unbraked/braked [kg] | 750/2000-2400 | 750/2000-2400 | 750/2000-2400 | 750/2400 | 750/2400 | 750/2400 |
| Maximum front/rear axle load [kg] | 1145/1400 | 1195/ 1415 | 1220/ 1425 | 1345/ 1500 | 1250/1415 | 1220/1425 |
| Maximum vertical load on the tow bar [kg] | 100 | 100 | 100 | 100 | 100 | 100 |
| Maximum load on roof/carrier [kg] | 100 /- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 525 | 525 | 525 | 525 | 525 | 525 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1430 | -/1430 | -/1430 | -/1430 | -/1430 | -/1430 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 60-68 | 68 | 68 | 68 | 68 | 68 |
| AdBlue tank volume [l] | 20.5 | 20.5 | 20.5 | 21.8 | 21.8 | 21.8 |
| Air resistance [Cd] | 0.30 | 0.30 | 0.32 | 0.31 | 0.30 | 0.30 |
| Front suspension | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone | double wishbone |
| Rear suspension | multilink | multilink | multilink | multilink | multilink | multilink |
| Tyre dimensions front | 225/60 R18 104W XL | 225/60R18 104W XL | 245/45 R20103W XL | 225/60 R18 104W XL | 225/60 R18 104W XL | 245/45 R20 103W XL |
| Tyre dimensions rear | 225/60 R18 104W XL | 225/60R18 104W XL | 275/40 R20106W XL | 225/60 R18 104W XL | 225/60 R18 104W XL | 275/40 R20 106W XL |
| Wheel size front | 7J x 18 | 7J x 18 | 8J x 20 | 7J x 18 | 7J x 18 | 8J x 20 |
| Wheel size rear | 7J x 18 | 7J x 18 | 9,5J x 20 | 7J x 18 | 7J x 18 | 9,5J x 20 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electro-mechanical power steering Servotronic | Electro-mechanical power steering Servotronic | Electro-mechanical power steering Servotronic | Electro-mechanical power steering Servotronic | Electro-mechanical power steering Servotronic | Electro-mechanical power steering Servotronic |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 12.1/- | 12.1/- | 12.1/- | 12.1/- | 12.1/- | 12.1/- |
| Overall length [mm] | 4752 | 4752 | 4733 | 4752 | 4752 | 4752 |
| Overall width without/including mirrors [mm] | 1918/2138 | 1918/2138 | 1938/- | 1918/2138 | 1918/2138 | 1938/- |
| Overall height [mm] | 1621 | 1621 | 1621 | 1621 | 1621 | 1621 |
| Wheelbase [mm] | 2864 | 2864 | 2864 | 2864 | 2864 | 2864 |
| Front wheel track [mm] | 1620 | 1620 | 1615 | 1620 | 1620 | 1615 |
| Rear wheel track [mm] | 1666 | 1666 | 1624 | 1666 | 1666 | 1624 |
| Forward overhang [mm] | 861 | 861 | 861 | 861 | 861 | 861 |
| Rear overhang [mm] | 1027 | 1027 | 1027 | 1027 | 1027 | 1027 |
| Clearance [mm] | 204 | 204 | 204 | 204 | 204 | 204 |
| Wading depth [mm] | 500 | 500 | 500 | 500 | 500 | 500 |
| Approach angle front [°] | 25,0 | 25,0 | 25,0 | 25.0 | 25.0 | 25.0 |
| Approach angle rear [°] | 21.9 | 21.9 | 21.9 | 21.9 | 21.9 | 21.9 |
| Transition angle [°] | 20.0 | 20.0 | 20.0 | 20.0 | 20.0 | 20.0 |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1024 | 1024 | 1024 | 1024 | 1024 | 1024 |
| Headroom rear [mm] | 953 | 953 | 953 | 953 | 953 | 953 |
| Front elbow/shoulder width [mm] | 1522/- | 1522/- | 1522/- | 1522/- | 1522/- | 1522/- |
| Rear elbow/shoulder width [mm] | 1478/- | 1478/- | 1478/- | 1478/- | 1478/- | 1478/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
