BMW X4
Date of manufacture
3/2014 – 3/2018 (SUV)
Platform
-
Manufacturing locations
Greer, South Carolina, USA
Kaliningrad, Russia
Designer
Christopher Weil
Tags
Compact SUV
German cars
The BMW X4 is a luxury SUV that was first produced in 2014. This model is manufactured in the United States and Russia and offers a wide range of petrol and diesel engines. The most powerful model is the X4 M40i with 265 kW, which reaches a top speed of 250 km/h. The most fuel-efficient version is the xDrive20d with a combined fuel consumption of 5.2 l/100 km and CO2 emissions of 138 g/km. All this plus a luggage compartment volume of 500 l.
Car body style
SUV
Date of manufacture
3/2014 – 3/2018Internal designation
F26Engine size
Technical data
SUV
| X4 xDrive20i | X4 xDrive28i | X4 xDrive35i | X4 M40i | xDrive20d | xDrive20d | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | from 10/2015 to | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 6/24 | 6/24 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1997 | 1997 | 2979 | 2979 | 1995 | 1995 |
| Maximum output / speed [kW/min-1] | 135/5000-6250 | 180/5000-6500 | 225/5800-6400 | 265/5800-6000 | 140/4000 | 140/4000 |
| Maximum torque [Nm/min-1] | 270/1250-4500 | 350/1250-4800 | 400/1200-5000 | 465/1350-5250 | 400/1750-2500 | 400/1750-2500 |
| Bore and stroke [mm x mm] | 84,0 x 90,1 | 84,0 x 90,1 | 84,0 x 89,6 | 84,0 x 89,6 | 84,0 x 90,0 | 84,0 x 90,0 |
| Compression ratio | 10,0:1 | 10,0:1 | 10,2:1 | 10,2:1 | 16,5:1 | 16,5:1 |
| Oil volume [l] | 5.75 | 5.75 | 6.5 | 6.5 | - | - |
| Coolant volume [l] | 7.5 | 7.5 | 9.6 | 6.7 | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | 6 gear manual | 8 gear automatic |
| Drive specifications |
|
|
|
|
|
|
| Top speed [km/h] | 212 | 232 | 247 | 250 | 212 | 212 |
| Acceleration 0–100 km/h [s] | 8.1 | 6.4 | 5.5 | 4.9 | 8.0 | 8.0 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 9.0-9.2 | 9.1-9.3 | 10.7 | 11.3 | 6.1-6.3 | 5.6-5.8 |
| Out of town [l] | 6.1-6.3 | 6.2-6.3 | 6.9 | 7.0 | 5.0-5.1 | 5.0-5.1 |
| Combined [l] | 7.2-7.3 | 7.3-7.4 | 8.3 | 8.6 | 5.4-5.6 | 5.2-5.4 |
| CO2 emissions [g/km] | 168-171 | 169-172 | 193 | 199 | 143-146 | 138-141 |
| Emission standard | EU6 | EU6 | EU6 | EU6 | EU6 | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1810 | 1845 | 1890 | 1915 | 1805 | 1820 |
| Overall weight [kg] | 2325 | 2360 | 2405 | 2430 | 2320 | 2335 |
| Maximum trailer weight unbraked/braked [kg] | 750/2400 | 750/2400 | 750/2400 | 750/2400 | 750/2000 | 750/2400 |
| Maximum front/rear axle load [kg] | 1085/1320 | 1120/1320 | 1140/1330 | 1160/1330 | 1070/1320 | 1085/1330 |
| Maximum vertical load on the tow bar [kg] | 100 | 100 | 100 | 100 | 100 | 100 |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 500 | 500 | 500 | 500 | 500 | 500 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1400 | -/1400 | -/1400 | -/1400 | -/1400 | -/1400 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 67 | 67 | 67 | 67 | 67 | 67 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.33 | 0.34 | 0.34 | 0.36 | 0.33 | 0.33 |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 225/60 R17 99V | 225/60 R17 99V | 245/50 R18 100W | 245/45 R19 98W/Y | 225/60 R17 99V | 225/60 R17 99V |
| Tyre dimensions rear | 225/60 R17 99V | 225/60 R17 99V | 245/50 R18 100W | 275/40 R19 101W/Y | 225/60 R17 99V | 225/60 R17 99V |
| Wheel size front | 7.5J x 17 | 7.5J x 17 | 8.0J x 18 | 8.5J x 19 | 7.5J x 17 | 7.5J x 17 |
| Wheel size rear | 7.5J x 17 | 7.5J x 17 | 8.0J x 18 | 9.5J x 19 | 7.5J x 17 | 7.5J x 17 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | -/11.9 | -/11.9 | -/11.9 | -/11.9 | -/11.9 | -/11.9 |
| Overall length [mm] | 4671 | 4671 | 4671 | 4671 | 4671 | 4671 |
| Overall width without/including mirrors [mm] | 1881/2089 | 1881/2089 | 1881/2089 | 1901/- | 1881/2089 | 1881/2089 |
| Overall height [mm] | 1624 | 1624 | 1624 | 1624 | 1624 | 1624 |
| Wheelbase [mm] | 2810 | 2810 | 2810 | 2810 | 2810 | 2810 |
| Front wheel track [mm] | 1616 | 1616 | 1616 | 1600 | 1616 | 1616 |
| Rear wheel track [mm] | 1632 | 1632 | 1632 | 1600 | 1632 | 1632 |
| Forward overhang [mm] | 861 | 861 | 861 | - | 861 | 861 |
| Rear overhang [mm] | 1000 | 1000 | 1000 | - | 1000 | 1000 |
| Clearance [mm] | 204 | 204 | 204 | 204 | 204 | 204 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1015 | 1015 | 1015 | 1015 | 1015 | 1015 |
| Headroom rear [mm] | 950 | 950 | 950 | 950 | 950 | 950 |
| Front elbow/shoulder width [mm] | 1482/- | 1482/- | 1482/- | 1482/- | 1482/- | 1482/- |
| Rear elbow/shoulder width [mm] | 1458/- | 1458/- | 1458/- | 1458/- | 1458/- | 1458/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| xDrive30d | xDrive35d | |||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | ||||
| Engine type | Diesel supercharged | Diesel supercharged | ||||
| Number of cylinders/valves | 6/24 | 6/24 | ||||
| Engine displacement [cm³] | 2993 | 2993 | ||||
| Maximum output / speed [kW/min-1] | 190/4000 | 230/4400 | ||||
| Maximum torque [Nm/min-1] | 560/1500-3000 | 630/1500-2500 | ||||
| Bore and stroke [mm x mm] | 84,0 x 90,0 | 84,0 x 90,0 | ||||
| Compression ratio | 16,5:1 | 16,5:1 | ||||
| Oil volume [l] | 7.2 | 7.2 | ||||
| Coolant volume [l] | 10.0 | 10.0 | ||||
| Technical specifications |
|
| ||||
| Drive axle | 4x4 | 4x4 | ||||
| Gearbox | 8 gear automatic | 8 gear automatic | ||||
| Drive specifications |
|
| ||||
| Top speed [km/h] | 234 | 247 | ||||
| Acceleration 0–100 km/h [s] | 5.8 | 5.2 | ||||
| Acceleration 0–80 km/h [s] | - | - | ||||
| Acceleration 80–120 km/h [s] | - | - | ||||
| City [l] | 6.5-6.6 | 6.7 | ||||
| Out of town [l] | 5.6-5.7 | 5.5 | ||||
| Combined [l] | 5.9-6.1 | 6.0 | ||||
| CO2 emissions [g/km] | 156-159 | 157 | ||||
| Emission standard | EU6 | EU6 | ||||
| Standard for fuel consumption measurement | - | - | ||||
| Energy class | - | - | ||||
| Stationary vehicle noise [dB] | - | - | ||||
| Driving noise [dB] | - | - | ||||
| Standby weight [kg] | 1895 | 1935 | ||||
| Overall weight [kg] | 2410 | 2440 | ||||
| Maximum trailer weight unbraked/braked [kg] | 750/2400 | 750/2400 | ||||
| Maximum front/rear axle load [kg] | 1145/1330 | 1180/1330 | ||||
| Maximum vertical load on the tow bar [kg] | 100 | 100 | ||||
| Maximum load on roof/carrier [kg] | 100/- | 100/- | ||||
| Boot volume [l] | 500 | 500 | ||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1400 | -/1400 | ||||
| Boot length [mm] | - | - | ||||
| Boot length with rear seats folded [mm] | - | - | ||||
| Boot width between wheels/max [mm] | - | - | ||||
| Boot height to headliner/ceiling [mm] | - | - | ||||
| Loading edge height [mm] | - | - | ||||
| Height of the open boot door [mm] | - | - | ||||
| Boot opening height [mm] | - | - | ||||
| Boot opening width min/max [mm] | - | - | ||||
| Number of doors | 5 | 5 | ||||
| Number of seats | 5 | 5 | ||||
| Fuel tank volume [l] | 67 | 67 | ||||
| AdBlue tank volume [l] | - | - | ||||
| Air resistance [Cd] | 0.34 | 0.35 | ||||
| Front suspension | MacPherson | MacPherson | ||||
| Rear suspension | five-link | five-link | ||||
| Tyre dimensions front | 225/60 R17 99V | 245/50 R18 100W | ||||
| Tyre dimensions rear | 225/60 R17 99V | 245/50 R18 100W | ||||
| Wheel size front | 7.5J x 17 | 8.0J x 18 | ||||
| Wheel size rear | 7.5J x 17 | 8.0J x 18 | ||||
| Brake dimensions front | - | - | ||||
| Brake dimensions rear | - | - | ||||
| Steering | - | - | ||||
| Number of steering wheel turns | - | - | ||||
| Turning diameter track/circumference [m] | -/11.9 | -/11.9 | ||||
| Overall length [mm] | 4671 | 4671 | ||||
| Overall width without/including mirrors [mm] | 1881/2089 | 1881/2089 | ||||
| Overall height [mm] | 1624 | 1624 | ||||
| Wheelbase [mm] | 2810 | 2810 | ||||
| Front wheel track [mm] | 1616 | 1616 | ||||
| Rear wheel track [mm] | 1632 | 1632 | ||||
| Forward overhang [mm] | 861 | 861 | ||||
| Rear overhang [mm] | 1000 | 1000 | ||||
| Clearance [mm] | 204 | 204 | ||||
| Wading depth [mm] | - | - | ||||
| Approach angle front [°] | - | - | ||||
| Approach angle rear [°] | - | - | ||||
| Transition angle [°] | - | - | ||||
| Climbing rate [°] | - | - | ||||
| Maximum side tilt [°] | - | - | ||||
| Headroom front [mm] | 1015 | 1015 | ||||
| Headroom rear [mm] | 950 | 950 | ||||
| Front elbow/shoulder width [mm] | 1482/- | 1482/- | ||||
| Rear elbow/shoulder width [mm] | 1458/- | 1458/- | ||||
| Legroom front knees/total [mm] | - | - | ||||
| Legroom rear knees/total [mm] | - | - |
Gallery
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
