Basic information Technical Specifications Gallery

BMW i8

Date of manufacture

4/2014 – 2017 (Coupé)

Platform

Manufacturing locations

Leipzig, Germany

Designer

Richard Kim

Benoit Jacob

Car body style

Coupé

Date of manufacture

4/2014 – 2017

Internal designation

Engine size

BMW i8

Technical data

Coupé

	BMW i8
Date of sale	-
Engine type	Petrol supercharged + Electric
Number of cylinders/valves	3/12
Engine displacement [cm³]	1499
Maximum output / speed [kW/min-1]	170/5800 96/4800 el. 266 total
Maximum torque [Nm/min-1]	320/3700 250/0 el. 570 total
Bore and stroke [mm x mm]	82,0 x 94,5
Compression ratio	9,5:1
Oil volume [l]	-
Coolant volume [l]	-
Technical specifications	Plug‐in Hybrid direct injection turbo-supercharged TwinScroll variable timing of intake and exhaust valves Double-VANOS start&stop system brake energy recuperation

Drive axle	4x4
Gearbox	6 + 2 gear automatic
Drive specifications	all-wheel drive (electric motor on the front axle and internal combustion engine at the rear) separate automatic gearbox for electric motor(2 gears) and combustion engine (6 gears)

Top speed [km/h]	250 [120 el.]
Acceleration 0–100 km/h [s]	4.4
Acceleration 0–80 km/h [s]	-
Acceleration 80–120 km/h [s]	4.0

City [l]	-
Out of town [l]	-
Combined [l]	2.1 [11,9 kWh]
CO2 emissions [g/km]	49

Emission standard	EU6
Standard for fuel consumption measurement	-
Energy class	-
Stationary vehicle noise [dB]	-
Driving noise [dB]	-

System voltage [V]	355
Battery type and capacity	Lithium-ion, 7.1 kWh (5.2 net)
Range with fully charged battery [km]	37
Charging time	to 80%, 2 hodiny, charger 3.7 kW (230V/16A) to 80%, 2.5 hodiny, charger 230V/10A
Number of modules/cells	6/96
Battery weight [kg]	-
Charger	-

Standby weight [kg]	1560
Overall weight [kg]	1930
Maximum trailer weight unbraked/braked [kg]	-
Maximum front/rear axle load [kg]	-
Maximum vertical load on the tow bar [kg]	-
Maximum load on roof/carrier [kg]	-

Boot volume [l]	154
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-
Boot length [mm]	-
Boot length with rear seats folded [mm]	-
Boot width between wheels/max [mm]	-
Boot height to headliner/ceiling [mm]	-
Loading edge height [mm]	-
Height of the open boot door [mm]	-
Boot opening height [mm]	-
Boot opening width min/max [mm]	-

Number of doors	2
Number of seats	4
Fuel tank volume [l]	30 [42 subject to a surcharge]
AdBlue tank volume [l]	-
Air resistance [Cd]	0.26
Front suspension	double wishbone
Rear suspension	five-link
Tyre dimensions front	195/50 R20
Tyre dimensions rear	215/45 R20
Wheel size front	7J x 20
Wheel size rear	7.5J x 20
Brake dimensions front	-
Brake dimensions rear	-
Steering	-
Number of steering wheel turns	-
Turning diameter track/circumference [m]	12,3/-

Overall length [mm]	4689
Overall width without/including mirrors [mm]	1942/2218
Overall height [mm]	1293
Wheelbase [mm]	2800
Front wheel track [mm]	1644
Rear wheel track [mm]	1721
Forward overhang [mm]	960
Rear overhang [mm]	929
Clearance [mm]	117
Wading depth [mm]	-
Approach angle front [°]	-
Approach angle rear [°]	-
Transition angle [°]	-
Climbing rate [°]	-
Maximum side tilt [°]	-

Headroom front [mm]	983
Headroom rear [mm]	824
Front elbow/shoulder width [mm]	1522/-
Rear elbow/shoulder width [mm]	1308/-
Legroom front knees/total [mm]	-
Legroom rear knees/total [mm]	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
