BMW i3

Date of manufacture

2017 – to this day (Five-door hatchback)

Platform

Manufacturing locations

Leipzig, Germany

Designer

Richard Kim

Car body style

Five-door hatchback

after upgrade (facelift)

Date of manufacture

2017 – to this day

Internal designation

Engine size

Petrol + Electric

Electric

Euro NCAP

Test year 2013

pre-facelift version (2013)

Technical data

Five-door hatchback

	i3 REX 94 Ah	i3s REX 94 Ah	i3 94 Ah	i3s 94 Ah	i3 120 Ah	i3s 120 Ah
Date of sale	from to 11/2018	from to 11/2018	from to 11/2018	from to 11/2018	from 11/2018 to	from 11/2018 to
Engine type	Petrol + Electric	Petrol + Electric	Electric	Electric	Electric	Electric
Number of cylinders/valves	2/8	2/8	-	-	-	-
Engine displacement [cm³]	647	647	-	-	-	-
Maximum output / speed [kW/min-1]	125 28/5000 combustion	135 28/5000 combustion	125	135	125	135
Maximum torque [Nm/min-1]	250/0 56/4500 combustion	270/0 56/4500 combustion	250/0	270/0	250/0	270/0
Bore and stroke [mm x mm]	79,0 x 66,0	79,0 x 66,0	-	-	-	-
Compression ratio	10,6:1	10,6:1	-	-	-	-
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	Synchronous electric motor combustion engine acts as a power generator	Synchronous electric motor combustion engine acts as a power generator	Synchronous electric motor	Synchronous electric motor	Synchronous electric motor	Synchronous electric motor

Drive axle	Rear	Rear	Rear	Rear	Rear	Rear
Gearbox	1 gear automatic	1 gear automatic	1 gear automatic	1 gear automatic	1 gear automatic	1 gear automatic
Drive specifications	constant ratio gearbox	constant ratio gearbox	constant ratio gearbox	constant ratio gearbox	constant ratio gearbox	constant ratio gearbox

Top speed [km/h]	150	160	150	160	150	160
Acceleration 0–100 km/h [s]	8.1	7.7	7.3	6.9	7.3	6.9
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	5.7	4.8	5.1	4.3	5.1	4.3

City [l]	-	-	-	-	-	-
Out of town [l]	-	-	-	-	-	-
Combined [l]	0.6 [11.9-11.5 kWh]	0.7 [12.5 kWh]	13.6-13.1 kWh	14.3 kWh	13.1 kWh	14.6-14.0 kWh
CO2 emissions [g/km]	13	14	0	0	0	0

Emission standard	EU6	EU6	-	-	-	-
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

System voltage [V]	353	353	353	353	352	352
Battery type and capacity	Lithium-ion, 33.2 kWh (27.2 net)	Lithium-ion, 33.2 kWh (27.2 net)	Lithium-ion, 33.2 kWh (27.2 net)	Lithium-ion, 33.2 kWh (27.2 net)	Lithium-ion, 42.2 kWh (37.9 net)	Lithium-ion, 42.2 kWh (37.9 net)
Range with fully charged battery [km]	190-200 [+ ~130 REX]	185-195 [+ ~130 REX ]	235-255	235-245	285-310	270-285
Charging time	to 80%, ~39 minutes, charger 50 kW to 80%, ~11 hodiny, charger 240V/10A to 80%, ~7:30 hodiny, charger 3.7 kW / 16A to 80%, ~3:45 hodiny, charger 7.4 kW / 32A to 80%, ~2:45 hodiny, charger 11 kW / 16A	to 80%, ~39 minutes, charger 50 kW to 80%, ~11 hodiny, charger 240V/10A to 80%, ~7:30 hodiny, charger 3.7 kW / 16A to 80%, ~3:45 hodiny, charger 7.4 kW / 32A to 80%, ~2:45 hodiny, charger 11 kW / 16A	to 80%, ~39 minutes, charger 50 kW to 80%, ~11 hodiny, charger 240V/10A to 80%, ~7:30 hodiny, charger 3.7 kW / 16A to 80%, ~3:45 hodiny, charger 7.4 kW / 32A to 80%, ~2:45 hodiny, charger 11 kW / 16A	to 80%, ~39 minutes, charger 50 kW to 80%, ~11 hodiny, charger 240V/10A to 80%, ~7:30 hodiny, charger 3.7 kW / 16A to 80%, ~3:45 hodiny, charger 7.4 kW / 32A to 80%, ~2:45 hodiny, charger 11 kW / 16A	to 80%, ~45 minutes, charger 50 kW to 80%, ~15 hodiny, charger 240V/10A to 80%, ~9:40 hodiny, charger 3.7 kW / 16A to 80%, ~3:10 hodiny, charger 11 kW / 16A	to 80%, ~45 minutes, charger 50 kW to 80%, ~15 hodiny, charger 240V/10A to 80%, ~9:40 hodiny, charger 3.7 kW / 16A to 80%, ~3:10 hodiny, charger 11 kW / 16A
Number of modules/cells	8/96	8/96	8/96	8/96	8/96	8/96
Battery weight [kg]	-	-	-	-	-	-
Charger	-	-	-	-	-	-

Standby weight [kg]	1440	1460	1320	1340	1345	1365
Overall weight [kg]	1760	1780	1670	1700	1710	1730
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	770/965	770/980
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	260	260	260	260	260	260
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1100	-/1100	-/1100	-/1100	-/1100	-/1100
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	4	4	4	4	4	4
Fuel tank volume [l]	9	9	-	-	-	-
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.30	0.33	0.29	0.32	0.29	0.30
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	five-link	five-link	five-link	five-link	five-link	five-link
Tyre dimensions front	155/70 R19	175/55 R20	155/70 R19	175/55 R20	155/70 R19	175/55 R20
Tyre dimensions rear	175/60 R19	195/50 R20	155/70 R19	195/50 R20	155/70 R19	195/50 R20
Wheel size front	5J x 19	5.5J x 20	5J x 19	5.5J x 20	5J x 19	5.5J x 20
Wheel size rear	5J x 19	6J x 20	5J x 19	6J x 20	5J x 19	6J x 20
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Electric power steering EPS	Electric power steering EPS	Electric power steering EPS	Electric power steering EPS	Electric power steering EPS	Electric power steering EPS
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	9.86/-	10.31/-	9.86/-	10.31/-	9.86/-	10.31/-

Overall length [mm]	4011	4006	4011	4006	4011	4006
Overall width without/including mirrors [mm]	1775/-	1791/-	1775/-	1791/-	1775/-	1791/-
Overall height [mm]	1598	1590	1598	1590	1598	1590
Wheelbase [mm]	2570	2570	2570	2570	2570	2570
Front wheel track [mm]	1571	1571	1571	1571	1571	1592
Rear wheel track [mm]	1556	1556	1576	1576	1576	1578
Forward overhang [mm]	715	714	715	714	715	714
Rear overhang [mm]	726	722	726	722	726	722
Clearance [mm]	139	131	139	131	139	131
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	1007	1007	1007	1007	1007	1007
Headroom rear [mm]	946	946	946	946	946	946
Front elbow/shoulder width [mm]	1392/-	1392/-	1392/-	1392/-	1392/-	1392/-
Rear elbow/shoulder width [mm]	1281/-	1281/-	1281/-	1281/-	1281/-	1281/-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
