BMW 1
Date of manufacture
2015 – 2019 (Three-door hatchback)
2015 – 2019 (Five-door hatchback)
Platform
-
Manufacturing locations
Leipzig, Germany
Regensburg, Germany
Designer
Nicolas Huet
Tags
C-segment
German cars
The BMW 1 model is a luxury hatchback that can be purchased as a three-door or five-door. The car has been manufactured in Germany since 2015 and offers a wide range of petrol and diesel engines. The most powerful model is the 140i xDrive 250 kW with a power of 250 kW, which reaches a speed of up to 250 km/h. The most economical variant, the 116d EfficientDynamics Edition 85 kW, has a fuel consumption of 3.4 l/100 km and CO2 emissions of 89 g/km. The trunk of the five-door hatchback has a size of 360 l and the three-door model has the same size. The car passed the EURONCAP safety test according to the 2012 methodology and received a rating of 5 out of 5.
Car body style
Three-door hatchback
after upgrade (facelift)
Date of manufacture
2015 – 2019Internal designation
F21Engine size
Petrol
Diesel
Five-door hatchback
after upgrade (facelift)
Date of manufacture
2015 – 2019Internal designation
F20Engine size
Petrol
Diesel
Technical data
Three-door hatchback
| 116i 80 kW | 116i 80 kW | 118i 100 kW | 118i 100 kW | 118i 100 kW | 118i 100 kW | |
|---|---|---|---|---|---|---|
| Date of sale | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from 9/2018 to 2019 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 3/12 | 3/12 | 4/16 | 3/12 | 4/16 | 3/12 |
| Engine displacement [cm³] | 1499 | 1499 | 1598 | 1499 | 1598 | 1499 |
| Maximum output / speed [kW/min-1] | 80/4500-6000 | 80/4250 | 100/4400-6450 | 100/4400 | 100/4400-6450 | 100/4400 |
| Maximum torque [Nm/min-1] | 180/1250 | 180/1250-4250 | 220/1350-4300 | 220/1250-4300 | 220/1250-4000 | 220/1250-4300 |
| Bore and stroke [mm x mm] | 82.0 x 94.6 | 82.0 x 94.6 | 77.0 x 85.8 | 82.0 x 94.6 | 77.0 x 85.8 | 82.0 x 94.6 |
| Compression ratio | 11.0:1 | 11.0:1 | 10.5:1 | 11.0:1 | 10.5:1 | 11.0:1 |
| Oil volume [l] | 4.25 | 4.25 | 4.2 | 4.25 | 4.2 | 4.25 |
| Coolant volume [l] | 7.7 | - | 6.4 | - | 7.0 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 6 gear manual | 6 gear manual | 6 gear manual | 6 gear manual | 8 gear automatic | 8 gear automatic |
| Drive specifications | - | - | - | - |
|
|
| Top speed [km/h] | 195 | 195 | 210 | 210 | 210 | 210 |
| Acceleration 0–100 km/h [s] | 10.9 | 10.9 | 8.5 | 8.5 | 8.7 | 8.7 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 14.8 | - | 10.6 | - | - | - |
| City [l] | 6.3-6.8 | 7.5-7.1 | 7.0-7.4 | 7.4-7.4 | 7.2-7.6 | 7.2-6.8 |
| Out of town [l] | 4.2-4.6 | 5.3-4.9 | 4.5-4.7 | 5.5-5.0 | 4.6-4.9 | 5.2-4.9 |
| Combined [l] | 5.0-5.4 | 6.0-5.9 | 5.4-5.7 | 6.2-5.9 | 5.6-5.9 | 5.9-5.6 |
| CO2 emissions [g/km] | 116-126 | 136-134 | 125-133 | 140-134 | 129-137 | 135-128 |
| Emission standard | EU6 | EU6d-TEMP | EU6 | EU6d-TEMP | EU6 | EU6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1375 | 1375 | 1375 | 1375 | 1390 | 1390 |
| Overall weight [kg] | 1865 | 1870 | 1865 | 1865 | 1880 | 1890 |
| Maximum trailer weight unbraked/braked [kg] | 650/1200 | 650/1200 | 650/1200 | 650/1300 | 650/1200 | 650/1300 |
| Maximum front/rear axle load [kg] | 850/1090 | 860/1090 | 865/1090 | 865/1090 | 865/1090 | 890/1090 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 75/- | 75 /- | 75/- | 75 /- | 75/- | 75 /- |
| Boot volume [l] | 360 | 360 | 360 | 360 | 360 | 360 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 3 | 3 | 3 | 3 | 3 | 3 |
| Number of seats | 4/5 | 4/5 | 4/5 | 4/5 | 4/5 | 4/5 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.31 | 0.31 | 0.31 | 0.31 | 0.31 | 0.31 |
| Front suspension | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H |
| Tyre dimensions rear | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H |
| Wheel size front | 6.5J x 16 | 6,5J x 16 | 6.5J x 16 | 6,5J x 16 | 6.5J x 16 | 6,5J x 16 |
| Wheel size rear | 6.5J x 16 | 6,5J x 16 | 6.5J x 16 | 6,5J x 16 | 6.5J x 16 | 6,5J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4329 | 4329 | 4329 | 4329 | 4329 | 4329 |
| Overall width without/including mirrors [mm] | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 |
| Overall height [mm] | 1421 | 1421 | 1421 | 1421 | 1421 | 1421 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1535 | 1535 | 1535 | 1535 | 1535 | 1535 |
| Rear wheel track [mm] | 1569 | 1569 | 1569 | 1569 | 1569 | 1569 |
| Forward overhang [mm] | 770 | 770 | 770 | 770 | 770 | 770 |
| Rear overhang [mm] | 869 | 869 | 869 | 869 | 869 | 869 |
| Clearance [mm] | 140 | 140 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 972 | 972 | 972 | 972 | 972 | 972 |
| Front elbow/shoulder width [mm] | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- |
| Rear elbow/shoulder width [mm] | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 120i 130 kW | 120i 130 kW | 120i 135 kW | 125i 160 kW | 125i 160 kW | 125i 165 kW | |
|---|---|---|---|---|---|---|
| Date of sale | from to 9/2018 | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from to 9/2018 | from 9/2018 to 2019 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1598 | 1598 | 1998 | 1997 | 1997 | 1998 |
| Maximum output / speed [kW/min-1] | 130/4800-6450 | 130/4800-6450 | 135/5000 | 160/5000 | 160/5000 | 165/5200-6500 |
| Maximum torque [Nm/min-1] | 250/1500 -4500 | 250/1500 -4500 | 270/1350-4600 | 310/1350 -4800 | 310/1350 -4800 | 310/1400-5000 |
| Bore and stroke [mm x mm] | 77.0 x 85.8 | 77.0 x 85.8 | 82.0 x 94.6 | 84.0 x 90.1 | 84.0 x 90.1 | 82.0 x 94.6 |
| Compression ratio | 10.5:1 | 10.5:1 | 11.0:1 | 10.0:1 | 10.0:1 | 10.2:1 |
| Oil volume [l] | 4.2 | 4.2 | 5.25 | 5.0 | 5.0 | 5.25 |
| Coolant volume [l] | 6.4 | 7.0 | - | 7.0 | 7.6 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 6 gear manual | 8 gear automatic | 8 gear automatic | 6 gear manual | 8 gear automatic | 8 gear automatic |
| Drive specifications | - |
|
| - |
|
|
| Top speed [km/h] | 225 | 222 | 225 | 245 | 243 | 243 |
| Acceleration 0–100 km/h [s] | 7.4 | 7.2 | 7.1 | 6.4 | 6.2 | 6.1 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 8.8 | - | - | 7.5 | 7.5 | - |
| City [l] | 7.4-7.8 | 7.1-7.6 | 7.3-7.2 | 8.6-8.9 | 8.5-8.7 | 7.4-7.4 |
| Out of town [l] | 4.7-4.9 | 4.6-4.9 | 5.5-5.1 | 5.4-5.4 | 5.1-5.2 | 5.7-5.4 |
| Combined [l] | 5.7-6.0 | 5.6-5.9 | 6.1-5.9 | 6.6-6.7 | 6.3-6.5 | 6.3-6.2 |
| CO2 emissions [g/km] | 132-139 | 129-137 | 139-134 | 154-157 | 148-151 | 144-140 |
| Emission standard | EU6 | EU6 | EU6d-TEMP | EU6 | EU6 | EU6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1375 | 1390 | 1450 | 1425 | 1445 | 1475 |
| Overall weight [kg] | 1865 | 1880 | 1940 | 1915 | 1935 | 1965 |
| Maximum trailer weight unbraked/braked [kg] | 670/1200 | 670/1200 | 670/1500 | 680/1200 | 680/1200 | 680/1500 |
| Maximum front/rear axle load [kg] | 870/1090 | 870/1090 | 930/1090 | 895/1120 | 895/1120 | 925/1100 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75 /- | 75/- | 75/- | 75 /- |
| Boot volume [l] | 360 | 360 | 360 | 360 | 360 | 360 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 3 | 3 | 3 | 3 | 3 | 3 |
| Number of seats | 4/5 | 4/5 | 4/5 | 4/5 | 4/5 | 4/5 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.31 | 0.31 | 0.31 | 0,32 | 0,32 | 0.32 |
| Front suspension | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 195/55 R16 87W | 195/55 R16 87W | 195/55 R16 87W | 205/50 R17 89Y | 205/50 R1789Y | 205/50R17 89Y |
| Tyre dimensions rear | 195/55 R16 87W | 195/55 R16 87W | 195/55 R16 87W | 205/50 R17 89Y | 205/50 R1789Y | 205/50R17 89Y |
| Wheel size front | 6.5J x 16 | 6.5J x 16 | 6,5J x 16 | 7J x 17 | 7J x 17 | 7J x 17 |
| Wheel size rear | 6.5J x 16 | 6.5J x 16 | 6,5J x 16 | 7J x 17 | 7J x 17 | 7J x 17 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4329 | 4329 | 4329 | 4329 | 4329 | 4329 |
| Overall width without/including mirrors [mm] | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 |
| Overall height [mm] | 1421 | 1421 | 1421 | 1421 | 1421 | 1421 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1535 | 1535 | 1535 | 1521 | 1521 | 1521 |
| Rear wheel track [mm] | 1569 | 1569 | 1569 | 1556 | 1556 | 1569 |
| Forward overhang [mm] | 770 | 770 | 770 | 770 | 770 | 770 |
| Rear overhang [mm] | 869 | 869 | 869 | 869 | 869 | 869 |
| Clearance [mm] | 140 | 140 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 972 | 972 | 972 | 972 | 972 | 972 |
| Front elbow/shoulder width [mm] | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- |
| Rear elbow/shoulder width [mm] | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 135i 240 kW | 135i 240 kW | 135i xDrive 240 kW | 140i 250 kW | 140i 250 kW | 140i 250 kW | |
|---|---|---|---|---|---|---|
| Date of sale | from to 9/2018 | from to 9/2018 | from to 9/2018 | from 2016 to 9/2018 | from 2016 to 9/2018 | from 9/2018 to 2019 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 6/24 | 6/24 | 6/24 | 6/24 | 6/24 | 6/24 |
| Engine displacement [cm³] | 2979 | 2979 | 2979 | 2998 | 2998 | 2998 |
| Maximum output / speed [kW/min-1] | 240/5800 -6000 | 240/5800 -6000 | 240/5800 -6000 | 250/5500 | 250/5500 | 250/5500 |
| Maximum torque [Nm/min-1] | 450/1300 -4500 | 450/1300 -4500 | 450/1300 -4500 | 500/1520-4500 | 500/1520-4500 | 500/1520-4500 |
| Bore and stroke [mm x mm] | 84.0 x 89.6 | 84.0 x 89.6 | 84.0 x 89.6 | 82.0 x 94,6 | 82.0 x 94,6 | 82.0 x 94,6 |
| Compression ratio | 10.2 :1 | 10.2 :1 | 10.2 :1 | 11,0:1 | 11,0:1 | 11,0:1 |
| Oil volume [l] | 6.5 | 6.5 | 6.5 | - | 6.5 | 6.5 |
| Coolant volume [l] | 6.9 | 7.1 | 7.1 | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | 4x4 | Rear | Rear | Rear |
| Gearbox | 6 gear manual | 8 gear automatic | 8 gear automatic | 6 gear manual | 8 gear automatic | 8 gear automatic |
| Drive specifications | - |
|
| - |
|
|
| Top speed [km/h] | 250 | 250 | 250 | 250 | 250 | 250 |
| Acceleration 0–100 km/h [s] | 5.1 | 4.9 | 4.7 | 4,8 | 4.6 | 4.6 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 5.0 | - | - | - | - | - |
| City [l] | 10.9 | 10.3 | 10.8 | 10,6 | 9,4 | 9.5-9.3 |
| Out of town [l] | 6.4 | 5.9 | 6.1 | 6,2 | 5.8 | 6.2-6.2 |
| Combined [l] | 8.0 | 7.5 | 7.8 | 7,8 | 7,1 | 7.4-7.4 |
| CO2 emissions [g/km] | 188 | 175 | 182 | 179 | 163 | 169-168 |
| Emission standard | EU6 | EU6 | EU6 | EU6d-TEMP | EU6d-TEMP | EU6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1505 | 1520 | 1590 | 1520 | 1545 | 1545 |
| Overall weight [kg] | 1995 | 2010 | 2065 | 2015 | 2040 | 2035 |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | - | - |
| Maximum front/rear axle load [kg] | 955/1120 | 955/1120 | 1010/1120 | - | 970/1120 | 970/1120 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | - | - | - |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75 /- | 75 /- | 75 /- |
| Boot volume [l] | 360 | 360 | 360 | 360 | 360 | 360 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 3 | 3 | 3 | 3 | 3 | 3 |
| Number of seats | 4/5 | 4/5 | 4/5 | 4/5 | 4/5 | 4/5 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.34 | 0.34 | 0.35 | 0,34 | 0,34 | 0,34 |
| Front suspension | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 225/40 ZR18 88Y | 225/40 ZR18 88Y | 225/40 ZR18 88Y | 225/40 R18 88Y | 225/40 R18 88Y | 225/40 R18 88Y |
| Tyre dimensions rear | 245/35 ZR18 92Y XL | 245/35 ZR18 92Y XL | 245/35 ZR18 92Y XL | 245/35 R18 92Y XL | 245/35 R18 92Y XL | 245/35 R18 92Y XL |
| Wheel size front | 7,5J x 18 | 7,5J x 18 | 7,5J x 18 | 7,5J x 18 | 7,5J x 18 | 7,5J x 18 |
| Wheel size rear | 8J x 18 | 8J x 18 | 8J x 18 | 8J x 18 | 8J x 18 | 8J x 18 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electro-mechanical power steering | Electro-mechanical power steering | Electro-mechanical power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 11.3/- | - | 10.9/- | 10.9/- |
| Overall length [mm] | 4324 | 4324 | 4324 | 4324 | 4324 | 4324 |
| Overall width without/including mirrors [mm] | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 |
| Overall height [mm] | 1411 | 1411 | 1411 | 1411 | 1411 | 1411 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1516 | 1516 | 1516 | 1516 | 1516 | 1516 |
| Rear wheel track [mm] | 1534 | 1534 | 1534 | 1534 | 1534 | 1534 |
| Forward overhang [mm] | 765 | 765 | 765 | 765 | 765 | 765 |
| Rear overhang [mm] | 869 | 869 | 869 | 869 | 869 | 869 |
| Clearance [mm] | 130 | 130 | 130 | 130 | 130 | 130 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 972 | 972 | 972 | 972 | 972 | 972 |
| Front elbow/shoulder width [mm] | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- |
| Rear elbow/shoulder width [mm] | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 140i xDrive 250 kW | 140i xDrive 250 kW | 114d 70 kW | 116d 85 kW | 116d 85 kW | 116d 85 kW | |
|---|---|---|---|---|---|---|
| Date of sale | from 2016 to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 |
| Engine type | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 6/24 | 6/24 | 3/12 | 3/12 | 3/12 | 3/12 |
| Engine displacement [cm³] | 2998 | 2998 | 1496 | 1496 | 1496 | 1496 |
| Maximum output / speed [kW/min-1] | 250/5500 | 250/5500 | 70/4000 | 85/4000 | 85/4000 | 85/4000 |
| Maximum torque [Nm/min-1] | 500/1520-4500 | 500/1520-4500 | 235/1750-2250 | 270/1750-2250 | 270/1750-2250 | 270/1750-2250 |
| Bore and stroke [mm x mm] | 82.0 x 94.6 | 82.0 x 94.6 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 |
| Compression ratio | 11.0:1 | 11.0:1 | 16.5:1 | 16.5:1 | 16.5:1 | 16.5:1 |
| Oil volume [l] | 6.5 | 6.5 | - | 4.4 | 4.8 | 4.4 |
| Coolant volume [l] | - | - | - | 7.0 | - | 7.0 |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | Rear | Rear | Rear | Rear |
| Gearbox | 8 gear automatic | 8 gear automatic | 6 gear manual | 6 gear manual | 6 gear manual | 8 gear automatic |
| Drive specifications |
|
| - | - | - |
|
| Top speed [km/h] | 250 | 250 | 185 | 200 | 200 | 200 |
| Acceleration 0–100 km/h [s] | 4.4 | 4.4 | 12,2 | 10.3 | 10.5 | 10.3 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | 11.7 | - | 11.7 |
| City [l] | 9,8 | 10.1-9.9 | 3,9-4,4 | 4.3-4.8 | 4.9-4.8 | 4.1-4.6 |
| Out of town [l] | 6,0 | 6.8-6.7 | 3,4-3,8 | 3.3-3.7 | 4.0-3.9 | 3.4-3.8 |
| Combined [l] | 7,4 | 8.0-7.9 | 3,6-4,0 | 3.7-4.1 | 4.3-4.2 | 3.6-4.1 |
| CO2 emissions [g/km] | 169 | 183-180 | 97-106 | 97-107 | 114-111 | 96-107 |
| Emission standard | EU6d-TEMP | EU6d-TEMP | EU6 | EU6 | EU6c | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1615 | 1615 | 1395 | 1395 | 1440 | 1425 |
| Overall weight [kg] | 2090 | 2090 | 1885 | 1885 | 1930 | 1915 |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | 690/1500 | 690/1500 | 690/1500 |
| Maximum front/rear axle load [kg] | 1040/1120 | 1040/1120 | - | 885/1090 | 890/1120 | 885/1090 |
| Maximum vertical load on the tow bar [kg] | - | - | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 75 /- | 75 /- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 360 | 360 | 360 | 360 | 360 | 360 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 3 | 3 | 3 | 3 | 3 | 3 |
| Number of seats | 4/5 | 4/5 | 4/5 | 4/5 | 4/5 | 4/5 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.35 | 0.35 | 0,30 | 0,30 | 0,3 | 0,30 |
| Front suspension | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 225/40 R18 88Y | 225/40 R18 88Y | 195/55 R16 87H | 195/55 R16 87H | 205/55 R16 91V | 195/55 R16 87H |
| Tyre dimensions rear | 245/35 R18 92Y XL | 245/35 R18 92Y XL | 195/55 R16 87H | 195/55 R16 87H | 205/55 R16 91V | 195/55 R16 87H |
| Wheel size front | 7.5J x 18 | 7.5J x 18 | 6,5J x 16 | 6,5J x 16 | 7J x 16 | 6,5J x 16 |
| Wheel size rear | 8J x 18 | 8J x 18 | 6,5J x 16 | 6,5J x 16 | 7J x 16 | 6,5J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electro-mechanical power steering | Electro-mechanical power steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.3/- | 11.3/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4324 | 4324 | 4329 | 4329 | 4329 | 4329 |
| Overall width without/including mirrors [mm] | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 |
| Overall height [mm] | 1411 | 1411 | 1421 | 1421 | 1421 | 1421 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1516 | 1516 | 1535 | 1535 | 1521 | 1535 |
| Rear wheel track [mm] | 1534 | 1534 | 1569 | 1569 | 1556 | 1569 |
| Forward overhang [mm] | 765 | 765 | 770 | 770 | 770 | 770 |
| Rear overhang [mm] | 869 | 869 | 869 | 869 | 869 | 869 |
| Clearance [mm] | 130 | 130 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 972 | 972 | 972 | 972 | 972 | 972 |
| Front elbow/shoulder width [mm] | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- |
| Rear elbow/shoulder width [mm] | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 116d 85 kW | 116d EfficientDynamics Edition 85 kW | 118d 110 kW | 118d 110 kW | 118d 110 kW | 118d 110 kW | |
|---|---|---|---|---|---|---|
| Date of sale | from 9/2018 to 2019 | from to 9/2018 | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from 9/2018 to 2019 |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 3/12 | 3/12 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1496 | 1496 | 1995 | 1995 | 1995 | 1995 |
| Maximum output / speed [kW/min-1] | 85/4000 | 85/4000 | 110/4000 | 110/4000 | 110/4000 | 110/4000 |
| Maximum torque [Nm/min-1] | 270/1750-2250 | 270/1750-2250 | 320/1500-3000 | 320/1500-3000 | 320/1500-3000 | 320/1500-3000 |
| Bore and stroke [mm x mm] | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 |
| Compression ratio | 16.5:1 | 16.5:1 | 16.5 :1 | 16.5:1 | 16.5 :1 | 16.5:1 |
| Oil volume [l] | 4.8 | 4.4 | 5.0 | 5.2 | 5.0 | 5.2 |
| Coolant volume [l] | - | 7.0 | 7.0 | - | 7.0 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 8 gear automatic | 6 gear manual | 6 gear manual | 6 gear manual | 8 gear automatic | 8 gear automatic |
| Drive specifications |
| - | - | - |
|
|
| Top speed [km/h] | 200 | 195 | 212 | 212 | 212 | 212 |
| Acceleration 0–100 km/h [s] | 10.5 | 10.4 | 8.3 | 8.4 | 8.1 | 8.2 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | 12.9 | 9.2 | - | - | - |
| City [l] | 5.0-5.0 | 3.9-4.4 | 5.0-5.2 | 5.3-5.1 | 4.7-4.9 | 5.2-5.1 |
| Out of town [l] | 4.2-4.1 | 3.1-3.5 | 3.6-3.8 | 4.1-3.9 | 3.6-3.8 | 4.2-4.1 |
| Combined [l] | 4.5-4.4 | 3.4-3.8 | 4.1-4.3 | 4.6-4.4 | 4.0-4.2 | 4.5-4.4 |
| CO2 emissions [g/km] | 118-116 | 89-101 | 109-114 | 120-115 | 105-110 | 118-115 |
| Emission standard | EU6c | EU6 | EU6 | EU6c | EU6 | EU6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1470 | 1395 | 1425 | 1470 | 1450 | 1495 |
| Overall weight [kg] | 1960 | 1885 | 1915 | 1960 | 1940 | 1985 |
| Maximum trailer weight unbraked/braked [kg] | 690/1500 | - | 690/1500 | 690/1500 | 690/1500 | 690/1500 |
| Maximum front/rear axle load [kg] | 890/1120 | 855/1090 | 900/1090 | 900/1120 | 900/1090 | 910/1120 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 360 | 360 | 360 | 360 | 360 | 360 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 3 | 3 | 3 | 3 | 3 | 3 |
| Number of seats | 4/5 | 4/5 | 4/5 | 4/5 | 4/5 | 4/5 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0,3 | 0.29 | 0.30 | 0,3 | 0.30 | 0,3 |
| Front suspension | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 205/55 R16 91V | 205/55 R16 91V | 195/55 R16 87W | 205/55 R16 91V | 195/55 R16 87W | 205/55 R16 91V |
| Tyre dimensions rear | 205/55 R16 91V | 205/55 R16 91V | 195/55 R16 87W | 205/55 R16 91V | 195/55 R16 87W | 205/55 R16 91V |
| Wheel size front | 7J x 16 | 7J x 16 | 6,5J x 16 | 7J x 16 | 6,5J x 16 | 7J x 16 |
| Wheel size rear | 7J x 16 | 7J x 16 | 6,5J x 16 | 7J x 16 | 6,5J x 16 | 7J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4329 | 4329 | 4329 | 4329 | 4329 | 4329 |
| Overall width without/including mirrors [mm] | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 |
| Overall height [mm] | 1421 | 1413 | 1421 | 1421 | 1421 | 1421 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1521 | 1523 | 1535 | 1521 | 1535 | 1521 |
| Rear wheel track [mm] | 1556 | 1558 | 1569 | 1556 | 1569 | 1556 |
| Forward overhang [mm] | 770 | 770 | 770 | 770 | 770 | 770 |
| Rear overhang [mm] | 869 | 869 | 869 | 869 | 869 | 869 |
| Clearance [mm] | 140 | 132 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 972 | 972 | 972 | 972 | 972 | 972 |
| Front elbow/shoulder width [mm] | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- |
| Rear elbow/shoulder width [mm] | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 118d xDrive 110 kW | 118d xDrive 110 kW | 120d 140 kW | 120d 140 kW | 120d 140 kW | 120d 140 kW | |
|---|---|---|---|---|---|---|
| Date of sale | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from 9/2018 to 2019 |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4 /16 | 4/16 | 4 /16 | 4/16 |
| Engine displacement [cm³] | 1995 | 1995 | 1995 | 1995 | 1995 | 1995 |
| Maximum output / speed [kW/min-1] | 110/4000 | 110/4000 | 140/4000 | 140/4000 | 140/4000 | 140/4000 |
| Maximum torque [Nm/min-1] | 320/1500-3000 | 320/1500-3000 | 400/1750 -2500 | 400/1750-2500 | 400/1750 -2500 | 400/1750-2500 |
| Bore and stroke [mm x mm] | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 |
| Compression ratio | 16.5 :1 | 16.5:1 | 16.5 :1 | 16.5:1 | 16.5 :1 | 16.5:1 |
| Oil volume [l] | 5.0 | 5.2 | 5.0 | 5.2 | 5.0 | 5.2 |
| Coolant volume [l] | 7.0 | - | 7.0 | - | 7.0 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | Rear | Rear | Rear | Rear |
| Gearbox | 8 gear automatic | 8 gear automatic | 6 gear manual | 6 gear manual | 8 gear automatic | 8 gear automatic |
| Drive specifications |
|
| - | - |
|
|
| Top speed [km/h] | 210 | 210 | 228 | 228 | 228 | 228 |
| Acceleration 0–100 km/h [s] | 8.4 | 8.5 | 7.1 | 7.2 | 7.0 | 7.1 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 9.5 | - | 7.2 | - | - | - |
| City [l] | 5.1-5.6 | 6.2-6.1 | 5.0-5.5 | 5.4-5.2 | 4.6-5.1 | 5.2-5.2 |
| Out of town [l] | 3.8-4.1 | 4.7-4.6 | 3.6-3.9 | 4.3-4.2 | 3.5-3.9 | 4.2-4.2 |
| Combined [l] | 4.3-4.7 | 5.2-5.1 | 4.1-4.5 | 4.7-4.6 | 3.9-4.3 | 4.6-4.5 |
| CO2 emissions [g/km] | 113-123 | 138-135 | 108-118 | 124-121 | 103-114 | 121-120 |
| Emission standard | EU6 | EU6c | EU6 | EU6c | EU6 | EU6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1495 | 1545 | 1445 | 1490 | 1460 | 1505 |
| Overall weight [kg] | 1970 | 2015 | 1935 | 1975 | 1950 | 1985 |
| Maximum trailer weight unbraked/braked [kg] | 710/1500 | 710/1500 | 710/1500 | 710/1500 | 710/1500 | 710/1500 |
| Maximum front/rear axle load [kg] | 940/1090 | 950/1120 | 900/1090 | 910/1120 | 900/1090 | 910/1120 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75 /- | 75/- | 75 /- |
| Boot volume [l] | 360 | 360 | 360 | 360 | 360 | 360 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 3 | 3 | 3 | 3 | 3 | 3 |
| Number of seats | 4/5 | 4/5 | 4/5 | 4/5 | 4/5 | 4/5 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.31 | 0.31 | 0.30 | 0.31 | 0.30 | 0.31 |
| Front suspension | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V |
| Tyre dimensions rear | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V |
| Wheel size front | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 |
| Wheel size rear | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.3/- | 11.3/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4329 | 4329 | 4329 | 4329 | 4329 | 4329 |
| Overall width without/including mirrors [mm] | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 |
| Overall height [mm] | 1421 | 1421 | 1421 | 1421 | 1421 | 1421 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1522 | 1522 | 1521 | 1521 | 1521 | 1521 |
| Rear wheel track [mm] | 1556 | 1556 | 1556 | 1556 | 1556 | 1556 |
| Forward overhang [mm] | 770 | 770 | 770 | 770 | 770 | 770 |
| Rear overhang [mm] | 869 | 869 | 869 | 869 | 869 | 869 |
| Clearance [mm] | 140 | 140 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 972 | 972 | 972 | 972 | 972 | 972 |
| Front elbow/shoulder width [mm] | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- |
| Rear elbow/shoulder width [mm] | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 120d xDrive 140 kW | 120d xDrive 140 kW | 125d 165 kW | 125d 165 kW | |||
|---|---|---|---|---|---|---|
| Date of sale | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from 9/2018 to 2019 | ||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | ||
| Number of cylinders/valves | 4 /16 | 4/16 | 4 /16 | 4/16 | ||
| Engine displacement [cm³] | 1995 | 1995 | 1995 | 1995 | ||
| Maximum output / speed [kW/min-1] | 140/4000 | 140/4000 | 165/4400 | 165/4400 | ||
| Maximum torque [Nm/min-1] | 400/1750 -2500 | 400/1750-2500 | 450/1500 -3000 | 450/1500-3000 | ||
| Bore and stroke [mm x mm] | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | ||
| Compression ratio | 16.5 :1 | 16.5:1 | 16.5:1 | 16.5:1 | ||
| Oil volume [l] | 5.0 | 5.2 | 5.0 | 5.2 | ||
| Coolant volume [l] | 7.0 | - | 7.0 | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | 4x4 | 4x4 | Rear | Rear | ||
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | ||
| Drive specifications |
|
|
|
| ||
| Top speed [km/h] | 222 | 222 | 240 | 240 | ||
| Acceleration 0–100 km/h [s] | 6.8 | 6.9 | 6.3 | 6.4 | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | - | - | - | - | ||
| City [l] | 5.1-5.5 | 6.0-5.8 | 5,1-5.4 | 5.5 | ||
| Out of town [l] | 3.9-4.3 | 4.8-4.7 | 3.9-4.1 | 4.3 | ||
| Combined [l] | 4.3-4.7 | 5.2-5.1 | 4.3-4.6 | 4.8 | ||
| CO2 emissions [g/km] | 113-124 | 138-135 | 114-121 | 126 | ||
| Emission standard | EU6 | EU6d-TEMP | EU6 | EU6c | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | - | - | - | - | ||
| Driving noise [dB] | - | - | - | - | ||
| Standby weight [kg] | 1525 | 1570 | 1500 | 1550 | ||
| Overall weight [kg] | 2000 | 2045 | 1990 | 2020 | ||
| Maximum trailer weight unbraked/braked [kg] | 750/1500 | 750/1500 | 710/1500 | 710/1500 | ||
| Maximum front/rear axle load [kg] | 975/1090 | 975/1120 | 975/1090 | 940/1120 | ||
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | ||
| Maximum load on roof/carrier [kg] | 75/- | 75 /- | 75/- | 75 /- | ||
| Boot volume [l] | 360 | 360 | 360 | 360 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1200 | -/1200 | -/1200 | -/1200 | ||
| Boot length [mm] | - | - | - | - | ||
| Boot length with rear seats folded [mm] | - | - | - | - | ||
| Boot width between wheels/max [mm] | - | - | - | - | ||
| Boot height to headliner/ceiling [mm] | - | - | - | - | ||
| Loading edge height [mm] | - | - | - | - | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | - | - | - | - | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 3 | 3 | 3 | 3 | ||
| Number of seats | 4/5 | 4/5 | 4/5 | 4/5 | ||
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | ||
| AdBlue tank volume [l] | - | - | - | - | ||
| Air resistance [Cd] | 0.31 | 0.32 | 0.31 | 0.31 | ||
| Front suspension | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | ||
| Rear suspension | five-link | five-link | five-link | five-link | ||
| Tyre dimensions front | 205/55 R16 91V | 205/55 R16 91V | 205/50 R17 89W | 205/55 R17 89Y | ||
| Tyre dimensions rear | 205/55 R16 91V | 205/55 R16 91V | 205/50 R17 89W | 205/55 R17 89Y | ||
| Wheel size front | 7J x 16 | 7J x 16 | 7J x 17 | 7J x 17 | ||
| Wheel size rear | 7J x 16 | 7J x 16 | 7J x 17 | 7J x 17 | ||
| Brake dimensions front | - | - | - | - | ||
| Brake dimensions rear | - | - | - | - | ||
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | ||
| Number of steering wheel turns | - | - | - | - | ||
| Turning diameter track/circumference [m] | 11.3/- | 11.3/- | 10.9/- | 10.9/- | ||
| Overall length [mm] | 4329 | 4329 | 4329 | 4329 | ||
| Overall width without/including mirrors [mm] | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | ||
| Overall height [mm] | 1421 | 1421 | 1421 | 1421 | ||
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | ||
| Front wheel track [mm] | 1522 | 1522 | 1521 | 1521 | ||
| Rear wheel track [mm] | 1556 | 1556 | 1556 | 1556 | ||
| Forward overhang [mm] | 770 | 770 | 770 | 770 | ||
| Rear overhang [mm] | 869 | 869 | 869 | 869 | ||
| Clearance [mm] | 140 | 140 | 140 | 140 | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | - | - | - | - | ||
| Approach angle rear [°] | - | - | - | - | ||
| Transition angle [°] | - | - | - | - | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | ||
| Headroom rear [mm] | 972 | 972 | 972 | 972 | ||
| Front elbow/shoulder width [mm] | 1400/- | 1400/- | 1400/- | 1400/- | ||
| Rear elbow/shoulder width [mm] | 1417/- | 1417/- | 1417/- | 1417/- | ||
| Legroom front knees/total [mm] | - | - | - | - | ||
| Legroom rear knees/total [mm] | - | - | - | - |
Five-door hatchback
| 116i 80 kW | 116i 80 kW | 118i 100 kW | 118i 100 kW | 118i 100 kW | 118i 100 kW | |
|---|---|---|---|---|---|---|
| Date of sale | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from 9/2018 to 2019 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 3/12 | 3/12 | 4/16 | 3/12 | 4/16 | 3/12 |
| Engine displacement [cm³] | 1499 | 1499 | 1598 | 1499 | 1598 | 1499 |
| Maximum output / speed [kW/min-1] | 80/4500-6000 | 80/4250 | 100/4400-6450 | 100/4400 | 100/4400-6450 | 100/4400 |
| Maximum torque [Nm/min-1] | 180/1250 | 180/1250-4250 | 220/1350-4300 | 220/1250-4300 | 220/1250-4000 | 220/1250-4300 |
| Bore and stroke [mm x mm] | 82.0 x 94.6 | 82.0 x 94.6 | 77.0 x 85.8 | 82.0 x 94.6 | 77.0 x 85.8 | 82.0 x 94.6 |
| Compression ratio | 11.0:1 | 11.0:1 | 10.5:1 | 11.0:1 | 10.5:1 | 11.0:1 |
| Oil volume [l] | 4.25 | 4.25 | 4.2 | 4.25 | 4.2 | 4.25 |
| Coolant volume [l] | 7.7 | - | 6.4 | - | 7.0 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 6 gear manual | 6 gear manual | 6 gear manual | 6 gear manual | 8 gear automatic | 8 gear automatic |
| Drive specifications | - | - | - | - |
|
|
| Top speed [km/h] | 195 | 195 | 210 | 210 | 210 | 210 |
| Acceleration 0–100 km/h [s] | 10.9 | 10.9 | 8.5 | 8.5 | 8.7 | 8.7 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 14.8 | - | 10.6 | - | - | - |
| City [l] | 6.3-6.8 | 7.5-7.1 | 7.0-7.4 | 7.4-7.4 | 7.2-7.6 | 7.2-6.8 |
| Out of town [l] | 4.2-4.6 | 5.3-4.9 | 4.5-4.7 | 5.5-5.0 | 4.6-4.9 | 5.2-4.9 |
| Combined [l] | 5.0-5.4 | 6.0-5.9 | 5.4-5.7 | 6.2-5.9 | 5.6-5.9 | 5.9-5.6 |
| CO2 emissions [g/km] | 116-126 | 136-134 | 125-133 | 140-134 | 129-137 | 135-128 |
| Emission standard | EU6 | EU6d-TEMP | EU6 | EU6d-TEMP | EU6 | EU6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1380 | 1380 | 1380 | 1380 | 1395 | 1395 |
| Overall weight [kg] | 1870 | 1870 | 1870 | 1870 | 1885 | 1900 |
| Maximum trailer weight unbraked/braked [kg] | 650/1200 | 650/1200 | 650/1200 | 650/1300 | 650/1200 | 650/1300 |
| Maximum front/rear axle load [kg] | 850/1090 | 860/ 1090 | 865/1090 | 865 | 865/1090 | 895/1090 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 75/- | 75 /- | 75/- | 75 /- | 75/- | 75 /- |
| Boot volume [l] | 360 | 360 | 360 | 360 | 360 | 360 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.31 | 0.31 | 0.31 | 0.31 | 0.31 | 0.31 |
| Front suspension | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H |
| Tyre dimensions rear | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H | 195/55 R16 87H |
| Wheel size front | 6.5J x 16 | 6,5J x 16 | 6.5J x 16 | 6,5J x 16 | 6.5J x 16 | 6,5J x 16 |
| Wheel size rear | 6.5J x 16 | 6,5J x 16 | 6.5J x 16 | 6,5J x 16 | 6.5J x 16 | 6,5J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4329 | 4329 | 4329 | 4329 | 4329 | 4329 |
| Overall width without/including mirrors [mm] | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 |
| Overall height [mm] | 1421 | 1421 | 1421 | 1421 | 1421 | 1421 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1535 | 1535 | 1535 | 1535 | 1535 | 1535 |
| Rear wheel track [mm] | 1569 | 1569 | 1569 | 1569 | 1569 | 1569 |
| Forward overhang [mm] | 770 | 770 | 770 | 770 | 770 | 770 |
| Rear overhang [mm] | 869 | 869 | 869 | 869 | 869 | 869 |
| Clearance [mm] | 140 | 140 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 972 | 972 | 972 | 972 | 972 | 972 |
| Front elbow/shoulder width [mm] | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- |
| Rear elbow/shoulder width [mm] | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 120i 130 kW | 120i 130 kW | 120i 135 kW | 125i 160 kW | 125i 160 kW | 125i 165 kW | |
|---|---|---|---|---|---|---|
| Date of sale | from to 9/2018 | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from to 9/2018 | from 9/2018 to 2019 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1598 | 1598 | 1998 | 1997 | 1997 | 1998 |
| Maximum output / speed [kW/min-1] | 130/4800-6450 | 130/4800-6450 | 135/5000 | 160/5000 | 160/5000 | 165/5200-6500 |
| Maximum torque [Nm/min-1] | 250/1500 -4500 | 250/1500 -4500 | 270/1350-4600 | 310/1350 -4800 | 310/1350 -4800 | 310/1400-5000 |
| Bore and stroke [mm x mm] | 77.0 x 85.8 | 77.0 x 85.8 | 82.0 x 94.6 | 84.0 x 90.1 | 84.0 x 90.1 | 82.0 x 94.6 |
| Compression ratio | 10.5:1 | 10.5:1 | 11.0:1 | 10.0:1 | 10.0:1 | 10.2:1 |
| Oil volume [l] | 4.2 | 4.2 | 5.25 | 5.0 | 5.0 | 5.25 |
| Coolant volume [l] | 6.4 | 7.0 | - | 7.0 | 7.6 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 6 gear manual | 8 gear automatic | 8 gear automatic | 6 gear manual | 8 gear automatic | 8 gear automatic |
| Drive specifications | - |
|
| - |
|
|
| Top speed [km/h] | 225 | 222 | 225 | 245 | 243 | 243 |
| Acceleration 0–100 km/h [s] | 7.4 | 7.2 | 7.1 | 6.4 | 6.2 | 6.1 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 8.8 | - | - | 7.5 | 7.5 | - |
| City [l] | 7.4-7.8 | 7.1-7.6 | 7.3-7.2 | 8.6-8.9 | 8.5-8.7 | 7.4-7.4 |
| Out of town [l] | 4.7-4.9 | 4.6-4.9 | 5.5-5.1 | 5.4-5.4 | 5.1-5.2 | 5.7-5.4 |
| Combined [l] | 5.7-6.0 | 5.6-5.9 | 6.1-5.9 | 6.6-6.7 | 6.3-6.5 | 6.3-6.2 |
| CO2 emissions [g/km] | 132-139 | 129-137 | 139-134 | 154-157 | 148-151 | 144-140 |
| Emission standard | EU6 | EU6 | EU6d-TEMP | EU6 | EU6 | EU6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1380 | 1395 | 1455 | 1430 | 1450 | 1475 |
| Overall weight [kg] | 1870 | 1885 | 1945 | 1920 | 1940 | 1965 |
| Maximum trailer weight unbraked/braked [kg] | 670/1200 | 670/1200 | 670/1500 | 680/1200 | 680/1200 | 680/1500 |
| Maximum front/rear axle load [kg] | 870/1090 | 870/1090 | 930/1090 | 895/1120 | 895/1120 | 935/1100 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75 /- | 75/- | 75/- | 75 /- |
| Boot volume [l] | 360 | 360 | 360 | 360 | 360 | 360 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.31 | 0.31 | 0.31 | 0,32 | 0,32 | 0.32 |
| Front suspension | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 195/55 R16 87W | 195/55 R16 87W | 195/55 R16 87W | 205/50 R17 89Y | 205/50 R1789Y | 205/50 R17 89Y |
| Tyre dimensions rear | 195/55 R16 87W | 195/55 R16 87W | 195/55 R16 87W | 205/50 R17 89Y | 205/50 R1789Y | 205/50 R17 89Y |
| Wheel size front | 6.5J x 16 | 6.5J x 16 | 6,5J x 16 | 7J x 17 | 7J x 17 | 7J x 17 |
| Wheel size rear | 6.5J x 16 | 6.5J x 16 | 6,5J x 16 | 7J x 17 | 7J x 17 | 7J x 17 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4329 | 4329 | 4329 | 4329 | 4329 | 4329 |
| Overall width without/including mirrors [mm] | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 |
| Overall height [mm] | 1421 | 1421 | 1421 | 1421 | 1421 | 1421 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1535 | 1535 | 1535 | 1521 | 1521 | 1521 |
| Rear wheel track [mm] | 1569 | 1569 | 1569 | 1556 | 1556 | 1569 |
| Forward overhang [mm] | 770 | 770 | 770 | 770 | 770 | 770 |
| Rear overhang [mm] | 869 | 869 | 869 | 869 | 869 | 869 |
| Clearance [mm] | 140 | 140 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 972 | 972 | 972 | 972 | 972 | 972 |
| Front elbow/shoulder width [mm] | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- |
| Rear elbow/shoulder width [mm] | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 135i 240 kW | 135i 240 kW | 135i xDrive 240 kW | 140i 250 kW | 140i 250 kW | 140i 250 kW | |
|---|---|---|---|---|---|---|
| Date of sale | from to 9/2018 | from to 9/2018 | from to 9/2018 | from 2016 to 9/2018 | from 2016 to 9/2018 | from 9/2018 to 2019 |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 6/24 | 6/24 | 6/24 | 6/24 | 6/24 | 6/24 |
| Engine displacement [cm³] | 2979 | 2979 | 2979 | 2998 | 2998 | 2998 |
| Maximum output / speed [kW/min-1] | 240/5800 -6000 | 240/5800 -6000 | 240/5800 -6000 | 250/5500 | 250/5500 | 250/5500 |
| Maximum torque [Nm/min-1] | 450/1300 -4500 | 450/1300 -4500 | 450/1300 -4500 | 500/1520-4500 | 500/1520-4500 | 500/1520-4500 |
| Bore and stroke [mm x mm] | 84.0 x 89.6 | 84.0 x 89.6 | 84.0 x 89.6 | 82.0 x 94,6 | 82.0 x 94,6 | 82.0 x 94,6 |
| Compression ratio | 10.2 :1 | 10.2 :1 | 10.2 :1 | 11,0:1 | 11,0:1 | 11,0:1 |
| Oil volume [l] | 6.5 | 6.5 | 6.5 | - | 6.5 | 6.5 |
| Coolant volume [l] | 6.9 | 7.1 | 7.1 | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | 4x4 | Rear | Rear | Rear |
| Gearbox | 6 gear manual | 8 gear automatic | 8 gear automatic | 6 gear manual | 8 gear automatic | 8 gear automatic |
| Drive specifications | - |
|
| - |
|
|
| Top speed [km/h] | 250 | 250 | 250 | 250 | 250 | 250 |
| Acceleration 0–100 km/h [s] | 5.1 | 4.9 | 4.7 | 4,8 | 4.6 | 4.6 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 5.0 | - | - | - | - | - |
| City [l] | 10.9 | 10.3 | 10.8 | 10,6 | 9,4 | 9.5-9.3 |
| Out of town [l] | 6.4 | 5.9 | 6.1 | 6,2 | 5,8 | 6.2-6.2 |
| Combined [l] | 8.0 | 7.5 | 7.8 | 7,8 | 7,1 | 7.4-7.4 |
| CO2 emissions [g/km] | 188 | 175 | 182 | 179 | 163 | 169-168 |
| Emission standard | EU6 | EU6 | EU6 | EU6d-TEMP | EU6d-TEMP | EU6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1505 | 1525 | 1595 | 1525 | 1550 | 1550 |
| Overall weight [kg] | 1995 | 2015 | 2070 | 2015 | 2040 | 2040 |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | - | - |
| Maximum front/rear axle load [kg] | 955/1120 | 955/1120 | 1010/1120 | - | 970/1120 | 970/1120 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | - | - | - |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75 /- | 75 /- | 75 /- |
| Boot volume [l] | 360 | 360 | 360 | 360 | 360 | 360 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.34 | 0.34 | 0.35 | 0,34 | 0,34 | 0,34 |
| Front suspension | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 225/40 ZR18 88Y | 225/40 ZR18 88Y | 225/40 ZR18 88Y | 225/40 R18 88Y | 225/40 R18 88Y | 225/40 R18 88Y |
| Tyre dimensions rear | 245/35 ZR18 92Y XL | 245/35 ZR18 92Y XL | 245/35 ZR18 92Y XL | 245/35 R18 92Y XL | 245/35 R18 92Y XL | 245/35 R18 92Y XL |
| Wheel size front | 7,5J x 18 | 7,5J x 18 | 7,5J x 18 | 7,5J x 18 | 7,5J x 18 | 7,5J x 18 |
| Wheel size rear | 8J x 18 | 8J x 18 | 8J x 18 | 8J x 18 | 8J x 18 | 8J x 18 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electro-mechanical power steering | Electro-mechanical power steering | Electro-mechanical power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 11.3/- | - | 10.9/- | 10.9/- |
| Overall length [mm] | 4324 | 4324 | 4324 | 4324 | 4324 | 4324 |
| Overall width without/including mirrors [mm] | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 |
| Overall height [mm] | 1411 | 1411 | 1411 | 1411 | 1411 | 1411 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1516 | 1516 | 1516 | 1516 | 1516 | 1516 |
| Rear wheel track [mm] | 1534 | 1534 | 1534 | 1534 | 1534 | 1534 |
| Forward overhang [mm] | 765 | 765 | 765 | 765 | 765 | 765 |
| Rear overhang [mm] | 869 | 869 | 869 | 869 | 869 | 869 |
| Clearance [mm] | 130 | 130 | 130 | 130 | 130 | 130 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 972 | 972 | 972 | 972 | 972 | 972 |
| Front elbow/shoulder width [mm] | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- |
| Rear elbow/shoulder width [mm] | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 140i xDrive 250 kW | 140i xDrive 250 kW | 114d 70 kW | 116d 85 kW | 116d 85 kW | 116d 85 kW | |
|---|---|---|---|---|---|---|
| Date of sale | from 2016 to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 |
| Engine type | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 6/24 | 6/24 | 3/12 | 3/12 | 3/12 | 3/12 |
| Engine displacement [cm³] | 2998 | 2998 | 1496 | 1496 | 1496 | 1496 |
| Maximum output / speed [kW/min-1] | 250/5500 | 250/5500 | 70/4000 | 85/4000 | 85/4000 | 85/4000 |
| Maximum torque [Nm/min-1] | 500/1520-4500 | 500/1520-4500 | 235/1750-2250 | 270/1750-2250 | 270/1750-2250 | 270/1750-2250 |
| Bore and stroke [mm x mm] | 82.0 x 94.6 | 82.0 x 94.6 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 |
| Compression ratio | 11.0:1 | 11.0:1 | 16.5:1 | 16.5:1 | 16.5:1 | 16.5:1 |
| Oil volume [l] | 6.5 | 6.5 | - | 4.4 | 4.8 | 4.4 |
| Coolant volume [l] | - | - | - | 7.0 | - | 7.0 |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | Rear | Rear | Rear | Rear |
| Gearbox | 8 gear automatic | 8 gear automatic | 6 gear manual | 6 gear manual | 6 gear manual | 8 gear automatic |
| Drive specifications |
|
| - | - | - |
|
| Top speed [km/h] | 250 | 250 | 185 | 200 | 200 | 200 |
| Acceleration 0–100 km/h [s] | 4.4 | 4.4 | 12,2 | 10.3 | 10.5 | 10.3 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | 11.7 | - | 11.7 |
| City [l] | 9,8 | 10.1-9.9 | 3,9-4,4 | 4.3-4.8 | 4.9-4.8 | 4.1-4.6 |
| Out of town [l] | 6.0 | 6.8-6.7 | 3,4-3,8 | 3.3-3.7 | 4.0-3.9 | 3.4-3.8 |
| Combined [l] | 7,4 | 8.0-7.9 | 3,6-4,0 | 3.7-4.1 | 4.3-4.2 | 3.6-4.1 |
| CO2 emissions [g/km] | 169 | 183-180 | 97-106 | 97-107 | 114-111 | 96-107 |
| Emission standard | EU6d-TEMP | EU6d-TEMP | EU6 | EU6 | EU6c | EU6 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1615 | 1615 | 1395 | 1395 | 1440 | 1425 |
| Overall weight [kg] | 2090 | 2090 | 1885 | 1885 | 1930 | 1915 |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | 690/1500 | 690/1500 | 690/1500 |
| Maximum front/rear axle load [kg] | 1040/1120 | 1040/1120 | - | 885/1090 | 890/1120 | 885/1090 |
| Maximum vertical load on the tow bar [kg] | - | - | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 75 /- | 75 /- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 360 | 360 | 360 | 360 | 360 | 360 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.35 | 0.35 | 0,30 | 0,30 | 0,3 | 0,30 |
| Front suspension | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 225/40 R18 88Y | 225/40 R18 88Y | 195/55 R16 87H | 195/55 R16 87H | 205/55 R16 91V | 195/55 R16 87H |
| Tyre dimensions rear | 245/35 R18 92Y XL | 245/35 R18 92Y XL | 195/55 R16 87H | 195/55 R16 87H | 205/55 R16 91V | 195/55 R16 87H |
| Wheel size front | 7.5J x 18 | 7.5J x 18 | 6,5J x 16 | 6,5J x 16 | 7J x 16 | 6,5J x 16 |
| Wheel size rear | 8J x 18 | 8J x 18 | 6,5J x 16 | 6,5J x 16 | 7J x 16 | 6,5J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electro-mechanical power steering | Electro-mechanical power steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.3/- | 11.3/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4324 | 4324 | 4329 | 4329 | 4329 | 4329 |
| Overall width without/including mirrors [mm] | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 |
| Overall height [mm] | 1411 | 1411 | 1421 | 1421 | 1421 | 1421 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1516 | 1516 | 1535 | 1535 | 1521 | 1535 |
| Rear wheel track [mm] | 1534 | 1534 | 1569 | 1569 | 1556 | 1569 |
| Forward overhang [mm] | 765 | 765 | 770 | 770 | 770 | 770 |
| Rear overhang [mm] | 869 | 869 | 869 | 869 | 869 | 869 |
| Clearance [mm] | 130 | 130 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 972 | 972 | 972 | 972 | 972 | 972 |
| Front elbow/shoulder width [mm] | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- |
| Rear elbow/shoulder width [mm] | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 116d 85 kW | 116d EfficientDynamics Edition 85 kW | 118d 110 kW | 118d 110 kW | 118d 110 kW | 118d 110 kW | |
|---|---|---|---|---|---|---|
| Date of sale | from 9/2018 to 2019 | from to 9/2018 | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from 9/2018 to 2019 |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 3/12 | 3/12 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1496 | 1496 | 1995 | 1995 | 1995 | 1995 |
| Maximum output / speed [kW/min-1] | 85/4000 | 85/4000 | 110/4000 | 110/4000 | 110/4000 | 110/4000 |
| Maximum torque [Nm/min-1] | 270/1750-2250 | 270/1750-2250 | 320/1500-3000 | 320/1500-3000 | 320/1500-3000 | 320/1500-3000 |
| Bore and stroke [mm x mm] | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 |
| Compression ratio | 16.5:1 | 16.5:1 | 16.5 :1 | 16.5:1 | 16.5 :1 | 16.5:1 |
| Oil volume [l] | 4.8 | 4.4 | 5.0 | 5.2 | 5.0 | 5.2 |
| Coolant volume [l] | - | 7.0 | 7.0 | - | 7.0 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Rear | Rear | Rear | Rear | Rear | Rear |
| Gearbox | 8 gear automatic | 6 gear manual | 6 gear manual | 6 gear manual | 8 gear automatic | 8 gear automatic |
| Drive specifications |
| - | - | - |
|
|
| Top speed [km/h] | 200 | 195 | 212 | 212 | 212 | 212 |
| Acceleration 0–100 km/h [s] | 10.5 | 10.4 | 8.3 | 8.4 | 8.1 | 8.2 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | 12.9 | 9.2 | - | - | - |
| City [l] | 5.0-5.0 | 3.9-4.4 | 5.0-5.2 | 5.3-5.1 | 4.7-4.9 | 5.2-5.1 |
| Out of town [l] | 4.2-4.1 | 3.1-3.5 | 3.6-3.8 | 4.1-3.9 | 3.6-3.8 | 4.2-4.1 |
| Combined [l] | 4.5-4.4 | 3.4-3.8 | 4.1-4.3 | 4.6-4.4 | 4.0-4.2 | 4.5-4.4 |
| CO2 emissions [g/km] | 118-116 | 89-101 | 109-114 | 120-115 | 105-110 | 118-115 |
| Emission standard | EU6c | EU6 | EU6 | EU6c | EU6 | EU6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1470 | 1395 | 1425 | 1470 | 1450 | 1495 |
| Overall weight [kg] | 1960 | 1885 | 1915 | 1960 | 1940 | 1985 |
| Maximum trailer weight unbraked/braked [kg] | 690/1500 | - | 690/1500 | 690/1500 | 690/1500 | 690/1500 |
| Maximum front/rear axle load [kg] | 890/1120 | 855/1090 | 900/1090 | 910/1120 | 900/1090 | 910/1120 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 360 | 360 | 360 | 360 | 360 | 360 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0,3 | 0.29 | 0.30 | 0,3 | 0.30 | 0,3 |
| Front suspension | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 205/55 R16 91V | 205/55 R16 91V | 195/55 R16 87W | 205/55 R16 91V | 195/55 R16 87W | 205/55 R16 91V |
| Tyre dimensions rear | 205/55 R16 91V | 205/55 R16 91V | 195/55 R16 87W | 205/55 R16 91V | 195/55 R16 87W | 205/55 R16 91V |
| Wheel size front | 7J x 16 | 7J x 16 | 6,5J x 16 | 7J x 16 | 6,5J x 16 | 7J x 16 |
| Wheel size rear | 7J x 16 | 7J x 16 | 6,5J x 16 | 7J x 16 | 6,5J x 16 | 7J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4329 | 4329 | 4329 | 4329 | 4329 | 4329 |
| Overall width without/including mirrors [mm] | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 |
| Overall height [mm] | 1421 | 1413 | 1421 | 1421 | 1421 | 1421 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1521 | 1523 | 1535 | 1521 | 1535 | 1521 |
| Rear wheel track [mm] | 1556 | 1558 | 1569 | 1556 | 1569 | 1556 |
| Forward overhang [mm] | 770 | 770 | 770 | 770 | 770 | 770 |
| Rear overhang [mm] | 869 | 869 | 869 | 869 | 869 | 869 |
| Clearance [mm] | 140 | 132 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 972 | 972 | 972 | 972 | 972 | 972 |
| Front elbow/shoulder width [mm] | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- |
| Rear elbow/shoulder width [mm] | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 118d xDrive 110 kW | 118d xDrive 110 kW | 120d 140 kW | 120d 140 kW | 120d 140 kW | 120d 140 kW | |
|---|---|---|---|---|---|---|
| Date of sale | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from 9/2018 to 2019 |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4 /16 | 4/16 | 4 /16 | 4/16 |
| Engine displacement [cm³] | 1995 | 1995 | 1995 | 1995 | 1995 | 1995 |
| Maximum output / speed [kW/min-1] | 110/4000 | 110/4000 | 140/4000 | 140/4000 | 140/4000 | 140/4000 |
| Maximum torque [Nm/min-1] | 320/1500-3000 | 320/1500-3000 | 400/1750 -2500 | 400/1750-2500 | 400/1750 -2500 | 400/1750-2500 |
| Bore and stroke [mm x mm] | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 |
| Compression ratio | 16.5 :1 | 16.5:1 | 16.5 :1 | 16.5:1 | 16.5 :1 | 16.5:1 |
| Oil volume [l] | 5.0 | 5.2 | 5.0 | 5.2 | 5.0 | 5.2 |
| Coolant volume [l] | 7.0 | - | 7.0 | - | 7.0 | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | Rear | Rear | Rear | Rear |
| Gearbox | 8 gear automatic | 8 gear automatic | 6 gear manual | 6 gear manual | 8 gear automatic | 8 gear automatic |
| Drive specifications |
|
| - | - |
|
|
| Top speed [km/h] | 210 | 210 | 228 | 228 | 228 | 228 |
| Acceleration 0–100 km/h [s] | 8.4 | 8.5 | 7.1 | 7.2 | 7.0 | 7.1 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | 9.5 | - | 7.2 | - | - | - |
| City [l] | 5.1-5.6 | 6.2-6.1 | 5.0-5.5 | 5.4-5.2 | 4.6-5.1 | 5.2-5.2 |
| Out of town [l] | 3.8-4.1 | 4.7-4.6 | 3.6-3.9 | 4.3-4.2 | 3.5-3.9 | 4.2-4.2 |
| Combined [l] | 4.3-4.7 | 5.2-5.1 | 4.1-4.5 | 4.7-4.6 | 3.9-4.3 | 4.6-4.5 |
| CO2 emissions [g/km] | 113-123 | 138-135 | 108-118 | 124-121 | 103-114 | 121-120 |
| Emission standard | EU6 | EU6c | EU6 | EU6c | EU6 | EU6d-TEMP |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1500 | 1550 | 1450 | 1495 | 1465 | 1505 |
| Overall weight [kg] | 1975 | 2020 | 1940 | 1975 | 1955 | 1985 |
| Maximum trailer weight unbraked/braked [kg] | 710/1500 | 710/1500 | 710/1500 | 710/1500 | 710/1500 | 710/1500 |
| Maximum front/rear axle load [kg] | 940/1090 | 950/1120 | 900/1090 | 910/1120 | 900/1090 | 910/1120 |
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | 75 | 75 |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75 /- | 75/- | 75 /- |
| Boot volume [l] | 360 | 360 | 360 | 360 | 360 | 360 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 | -/1200 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | 52 | 52 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | 0.31 | 0.31 | 0.30 | 0.31 | 0.30 | 0.31 |
| Front suspension | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms |
| Rear suspension | five-link | five-link | five-link | five-link | five-link | five-link |
| Tyre dimensions front | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V |
| Tyre dimensions rear | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V | 205/55 R16 91V |
| Wheel size front | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 |
| Wheel size rear | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 | 7J x 16 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11.3/- | 11.3/- | 10.9/- | 10.9/- | 10.9/- | 10.9/- |
| Overall length [mm] | 4329 | 4329 | 4329 | 4329 | 4329 | 4329 |
| Overall width without/including mirrors [mm] | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 |
| Overall height [mm] | 1421 | 1421 | 1421 | 1421 | 1421 | 1421 |
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | 2690 | 2690 |
| Front wheel track [mm] | 1522 | 1522 | 1521 | 1521 | 1521 | 1521 |
| Rear wheel track [mm] | 1556 | 1556 | 1556 | 1556 | 1556 | 1556 |
| Forward overhang [mm] | 770 | 770 | 770 | 770 | 770 | 770 |
| Rear overhang [mm] | 869 | 869 | 869 | 869 | 869 | 869 |
| Clearance [mm] | 140 | 140 | 140 | 140 | 140 | 140 |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | 1018 | 1018 |
| Headroom rear [mm] | 972 | 972 | 972 | 972 | 972 | 972 |
| Front elbow/shoulder width [mm] | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- | 1400/- |
| Rear elbow/shoulder width [mm] | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- | 1417/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 120d xDrive 140 kW | 120d xDrive 140 kW | 125d 165 kW | 125d 165 kW | |||
|---|---|---|---|---|---|---|
| Date of sale | from to 9/2018 | from 9/2018 to 2019 | from to 9/2018 | from 9/2018 to 2019 | ||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | ||
| Number of cylinders/valves | 4 /16 | 4/16 | 4 /16 | 4/16 | ||
| Engine displacement [cm³] | 1995 | 1995 | 1995 | 1995 | ||
| Maximum output / speed [kW/min-1] | 140/4000 | 140/4000 | 165/4400 | 165/4400 | ||
| Maximum torque [Nm/min-1] | 400/1750 -2500 | 400/1750-2500 | 450/1500 -3000 | 450/1500-3000 | ||
| Bore and stroke [mm x mm] | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | 84.0 x 90.0 | ||
| Compression ratio | 16.5 :1 | 16.5:1 | 16.5:1 | 16.5:1 | ||
| Oil volume [l] | 5.0 | 5.2 | 5.0 | 5.2 | ||
| Coolant volume [l] | 7.0 | - | 7.0 | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | 4x4 | 4x4 | Rear | Rear | ||
| Gearbox | 8 gear automatic | 8 gear automatic | 8 gear automatic | 8 gear automatic | ||
| Drive specifications |
|
|
|
| ||
| Top speed [km/h] | 222 | 222 | 240 | 240 | ||
| Acceleration 0–100 km/h [s] | 6.8 | 6.9 | 6.3 | 6.4 | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | - | - | - | - | ||
| City [l] | 5.1-5.5 | 6.0-5.8 | 5,1-5.4 | 5.5 | ||
| Out of town [l] | 3.9-4.3 | 4.8-4.7 | 3.9-4.1 | 4.3 | ||
| Combined [l] | 4.3-4.7 | 5.2-5.1 | 4.3-4.6 | 4.8 | ||
| CO2 emissions [g/km] | 113-124 | 138-135 | 114-121 | 126 | ||
| Emission standard | EU6 | EU6d-TEMP | EU6 | EU6c | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | - | - | - | - | ||
| Driving noise [dB] | - | - | - | - | ||
| Standby weight [kg] | 1530 | 1575 | 1505 | 1550 | ||
| Overall weight [kg] | 2005 | 2050 | 1995 | 2020 | ||
| Maximum trailer weight unbraked/braked [kg] | 750/1500 | 750/1500 | 710/1500 | 710/1500 | ||
| Maximum front/rear axle load [kg] | 975/1090 | 975/1120 | 940/1115 | 940/ 1120 | ||
| Maximum vertical load on the tow bar [kg] | 75 | 75 | 75 | 75 | ||
| Maximum load on roof/carrier [kg] | 75/- | 75 /- | 75/- | 75 /- | ||
| Boot volume [l] | 360 | 360 | 360 | 360 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1200 | -/1200 | -/1200 | -/1200 | ||
| Boot length [mm] | - | - | - | - | ||
| Boot length with rear seats folded [mm] | - | - | - | - | ||
| Boot width between wheels/max [mm] | - | - | - | - | ||
| Boot height to headliner/ceiling [mm] | - | - | - | - | ||
| Loading edge height [mm] | - | - | - | - | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | - | - | - | - | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 5 | 5 | 5 | 5 | ||
| Number of seats | 5 | 5 | 5 | 5 | ||
| Fuel tank volume [l] | 52 | 52 | 52 | 52 | ||
| AdBlue tank volume [l] | - | - | - | - | ||
| Air resistance [Cd] | 0.31 | 0.32 | 0.31 | 0.31 | ||
| Front suspension | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | MacPherson, two separate lower arms | ||
| Rear suspension | five-link | five-link | five-link | five-link | ||
| Tyre dimensions front | 205/55 R16 91V | 205/55 R16 91V | 205/50 R17 89W | 205/55 R17 89Y | ||
| Tyre dimensions rear | 205/55 R16 91V | 205/55 R16 91V | 205/50 R17 89W | 205/55 R17 89Y | ||
| Wheel size front | 7J x 16 | 7J x 16 | 7J x 17 | 7J x 17 | ||
| Wheel size rear | 7J x 16 | 7J x 16 | 7J x 17 | 7J x 17 | ||
| Brake dimensions front | - | - | - | - | ||
| Brake dimensions rear | - | - | - | - | ||
| Steering | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | Electric power steering EPS | ||
| Number of steering wheel turns | - | - | - | - | ||
| Turning diameter track/circumference [m] | 11.3/- | 11.3/- | 10.9/- | 10.9/- | ||
| Overall length [mm] | 4329 | 4329 | 4329 | 4329 | ||
| Overall width without/including mirrors [mm] | 1765/1984 | 1765/1984 | 1765/1984 | 1765/1984 | ||
| Overall height [mm] | 1421 | 1421 | 1421 | 1421 | ||
| Wheelbase [mm] | 2690 | 2690 | 2690 | 2690 | ||
| Front wheel track [mm] | 1522 | 1522 | 1521 | 1521 | ||
| Rear wheel track [mm] | 1556 | 1556 | 1556 | 1556 | ||
| Forward overhang [mm] | 770 | 770 | 770 | 770 | ||
| Rear overhang [mm] | 869 | 869 | 869 | 869 | ||
| Clearance [mm] | 140 | 140 | 140 | 140 | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | - | - | - | - | ||
| Approach angle rear [°] | - | - | - | - | ||
| Transition angle [°] | - | - | - | - | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | 1018 | 1018 | 1018 | 1018 | ||
| Headroom rear [mm] | 972 | 972 | 972 | 972 | ||
| Front elbow/shoulder width [mm] | 1400/- | 1400/- | 1400/- | 1400/- | ||
| Rear elbow/shoulder width [mm] | 1417/- | 1417/- | 1417/- | 1417/- | ||
| Legroom front knees/total [mm] | - | - | - | - | ||
| Legroom rear knees/total [mm] | - | - | - | - |
Gallery
Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
Please always refer to the vehicle registration document or your authorised dealer for exact details.
