Audi TT
Date of manufacture
2018 – to this day (Coupé)
2018 – to this day (Roadster)
Platform
Volkswagen MQB Platform
Manufacturing locations
Győr, Hungary
Designer
Dany Garand
Tags
S-segment
German cars
The Audi TT is available in two versions - coupe and roadster. This model was developed in 2018 and is produced in Hungary on the Volkswagen MQB Platform. The engine range includes only petrol engines, the most powerful of which is the 294 kW TT RS engine, which can reach a maximum speed of 280 km/h and the best acceleration 0-100 km/h in 3.7 seconds. The lowest consumption 6.1 l/100 km has the 40 TFSI 145 kW version with CO2 emissions of 138 g/km. The luggage compartment volume is 305 l for the coupe and 280 l for the roadster. The model successfully passed the EURONCAP safety tests, where it received a rating of 4 out of 5.
Car body style
Coupé
after upgrade (facelift)
Date of manufacture
2018 – to this dayInternal designation
FV/8SRoadster
after upgrade (facelift)
Date of manufacture
2018 – to this dayInternal designation
FV/8S
Technical data
Coupé
| 40 TFSI 145 kW | 45 TFSI 180 kW | 45 TFSI 180 kW | 45 TFSI 180 kW quattro | TTS 225 kW | TT RS | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 5/20 |
| Engine displacement [cm³] | 1984 | 1984 | 1984 | 1984 | 1984 | 2480 |
| Maximum output / speed [kW/min-1] | 145/4400-6000 | 180/5500-6500 | 180/5500-6500 | 180/5500-6500 | 225/5400-6500 | 294/5850-7000 |
| Maximum torque [Nm/min-1] | 320/1500-4300 | 370/1600-4300 | 370/1600-4300 | 370/1600-4300 | 400/2000-5300 | 480/1700-5850 |
| Bore and stroke [mm x mm] | 82,5 x 92,8 | 82,5 x 92,8 | 82,5 x 92,8 | 82,5 x 92,8 | 82,5 x 92,8 | 82,5 x 92,8 |
| Compression ratio | 11,7:1 | 9,6:1 | 9,6:1 | 9,6:1 | 9,3:1 | 10,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | 4x4 | 4x4 | 4x4 |
| Gearbox | 7 gear automatic | 6 gear manual | 7 gear automatic | 7 gear automatic | 7 gear automatic | 7 gear automatic |
| Drive specifications |
| - |
|
|
|
|
| Top speed [km/h] | 250 | 250 | 250 | 250 | 250 | 250 [280 subject to a surcharge] |
| Acceleration 0–100 km/h [s] | 6,6 | 5,9 | 5,8 | 5,2 | 4,5 | 3,7 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 8,1-8,0 | 8,5 | 8,5-8,1 | 9,0 | 9,0 | 10,6-10,5 |
| Out of town [l] | 5,0-4,9 | 5,5-5,4 | 5,3-5,2 | 5,9 | 6,0 | 6,5-6,4 |
| Combined [l] | 6,1-6,0 | 6,6-6,5 | 6,5-6,3 | 7,0 | 7,1 | 8,0-7,9 |
| CO2 emissions [g/km] | 138-137 | 150-149 | 148-144 | 161-160 | 161 | 181 |
| Low speed [l] | - | - | 10,7 | - | 10,9 | 13,9 |
| Medium speed [l] | - | - | 7,0 | - | 7,9 | 9,0 |
| High speed [l] | - | - | 5,9 | - | 6,9 | 7,4 |
| Extra high speed [l] | - | - | 6,8 | - | 7,7 | 8,1 |
| Combined speed [l] | - | - | 7,4-7,1 | - | 7,9 | 8,9 |
| CO2 emissions [g/km] | - | - | 167-161 | - | 179 | 201 |
| Emission standard | Euro 6d-TEMP-EVAP | Euro 6d-TEMP-EVAP | Euro 6d-TEMP-EVAP - Euro 6d-TEMPEVAP-ISC | Euro 6d-TEMP-EVAP | Euro 6d-TEMP-EVAP - Euro 6d-TEMPEVAP-ISC | Euro 6d-TEMP - Euro 6d-ISC-FCM |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | 79,7 | - | 89,6 | 94,2 |
| Driving noise [dB] | - | - | 67 | - | 71 | 70 |
| Standby weight [kg] | 1345 | 1325 | 1360 | 1440 | 1480 | 1525 |
| Overall weight [kg] | 1705 | 1685 | 1720 | 1800 | 1815 | 1875 |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | - | - |
| Maximum front/rear axle load [kg] | - | - | 995/830 | - | 1025/905 | 1035/840 |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 305 | 305 | 305 | 305 | 305 | 305 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/712 | -/712 | -/712 | -/712 | -/712 | -/712 |
| Boot length [mm] | 824 | 824 | 824 | 824 | 824 | 824 |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | 1000/- | 1000/- | 1000/- | 1000/- | 1000/- | 1000/- |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | 813 | 813 | 813 | 813 | 803 | 803 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | -/953 | -/953 | -/953 | -/953 | -/953 | 953/- |
| Number of doors | 3 | 3 | 3 | 3 | 3 | 3 |
| Number of seats | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel tank volume [l] | 50 | 50 | 50 | 55 | 55 | 55 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | 0,31 | - | 0,31 | 0,33 |
| Front suspension | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser |
| Rear suspension | four-link | four-link | four-link | four-link | four-link | four-link, stabiliser bar |
| Tyre dimensions front | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 | 245/40 R18 93 Y | 245/35 R19 93 Y XL |
| Tyre dimensions rear | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 | 245/40 R18 93 Y | 245/35 R19 93 Y XL |
| Wheel size front | 8,0J x 17 | 8,0J x 17 | 8,0J x 17 | 8,0J x 17 | 8,5J x 15 | 9,0J x 19 |
| Wheel size rear | 8,0J x 17 | 8,0J x 17 | 8,0J x 17 | 8,0J x 17 | 8,5J x 15 | 9,0J x 19 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11,0/- | 11,0/- | 11,0/- | 11,0/- | 11,0/- | 11,0/- |
| Overall length [mm] | 4191 | 4191 | 4191 | 4191 | 4199 | 4201 |
| Overall width without/including mirrors [mm] | 1832/1966 | 1832/1966 | 1832/1966 | 1832/1966 | 1832/1966 | 1832/1966 |
| Overall height [mm] | 1353 | 1353 | 1353 | 1353 | 1353 | 1344 |
| Wheelbase [mm] | 2505 | 2505 | 2505 | 2505 | 2505 | 2505 |
| Front wheel track [mm] | 1572 | 1572 | 1572 | 1572 | 1574 | 1564 |
| Rear wheel track [mm] | 1552 | 1552 | 1552 | 1552 | 1553 | 1543 |
| Forward overhang [mm] | 893 | 893 | 893 | 893 | 890 | 893 |
| Rear overhang [mm] | 793 | 793 | 793 | 793 | 804 | 803 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | 14,7 | - | 13,9 | - |
| Approach angle rear [°] | - | - | 12,2 | - | 11,5 | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 993 | 993 | 993 | 993 | 993 | 993 |
| Headroom rear [mm] | 585 | 585 | 585 | 585 | 585 | 858 |
| Front elbow/shoulder width [mm] | 1449/1362 | 1449/1362 | 1449/1362 | 1449/1362 | 1449/1362 | 1449/1362 |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
Roadster
| 40 TFSI 145 kW | 45 TFSI 180 kW | 45 TFSI 180 kW | 45 TFSI 180 kW quattro | TTS 225 kW | TT RS | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 | 5/20 |
| Engine displacement [cm³] | 1984 | 1984 | 1984 | 1984 | 1984 | 2480 |
| Maximum output / speed [kW/min-1] | 145/4400-6000 | 180/5500-6500 | 180/5500-6500 | 180/5500-6500 | 225/5400-6500 | 294/5850-7000 |
| Maximum torque [Nm/min-1] | 320/1500-4300 | 370/1600-4300 | 370/1600-4300 | 370/1600-4300 | 400/2000-5300 | 480/1700-5850 |
| Bore and stroke [mm x mm] | 82,5 x 92,8 | 82,5 x 92,8 | 82,5 x 92,8 | 82,5 x 92,8 | 82,5 x 92,8 | 82,5 x 92,8 |
| Compression ratio | 11,7:1 | 9,6:1 | 9,6:1 | 9,6:1 | 9,3:1 | 10,0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | 4x4 | 4x4 | 4x4 |
| Gearbox | 7 gear automatic | 6 gear manual | 7 gear automatic | 7 gear automatic | 7 gear automatic | 7 gear automatic |
| Drive specifications |
| - |
|
|
|
|
| Top speed [km/h] | 247 | 250 | 250 | 250 | 250 | 250 [280 subject to a surcharge] |
| Acceleration 0–100 km/h [s] | 6,9 | 6,1 | 6,0 | 5,5 | 4,8 | 3,9 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 8,3 | 8,6 | 8,7-8,6 | 9,2-9,1 | 9,2 | 11,1-10,6 |
| Out of town [l] | 5,2-5,1 | 5,7-5,6 | 5,5-5,4 | 6,2-6,1 | 6,2-6,1 | 7,3-6,5 |
| Combined [l] | 6,3 | 6,8-6,7 | 6,7-6,6 | 7,3-7,2 | 7,3-7,2 | 8,7-8,0 |
| CO2 emissions [g/km] | 145-143 | 154-153 | 152-151 | 166-164 | 166-165 | 199-182 |
| Low speed [l] | - | - | 10,8 | - | 11,2 | 14,1 |
| Medium speed [l] | - | - | 7,2 | - | 8,1 | 9,2 |
| High speed [l] | - | - | 6,1 | - | 7,1 | 7,7 |
| Extra high speed [l] | - | - | 7,0 | - | 7,9 | 8,5 |
| Combined speed [l] | - | - | 7,6-7,3 | - | 8,1 | 9,2 |
| CO2 emissions [g/km] | - | - | 172-165 | - | 184 | 208 |
| Emission standard | Euro 6d-TEMP-EVAP | Euro 6d-TEMP-EVAP | Euro 6d-TEMP-EVAP - Euro 6d-TEMPEVAP-ISC | Euro 6d-TEMP-EVAP | Euro 6d-TEMP-EVAP - Euro 6d-TEMPEVAP-ISC | Euro 6d-TEMP - Euro 6d-ISC-FCM |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | 79,7 | - | 89,6 | 94,2 |
| Driving noise [dB] | - | - | 67 | - | 71 | 70 |
| Standby weight [kg] | 1435 | 1415 | 1450 | 1530 | 1570 | 1615 |
| Overall weight [kg] | 1715 | 1695 | 1730 | 1810 | 1825 | 1885 |
| Maximum trailer weight unbraked/braked [kg] | - | - | - | - | - | - |
| Maximum front/rear axle load [kg] | - | - | 1015/770 | - | 1050/835 | 1070/815 |
| Maximum vertical load on the tow bar [kg] | - | - | - | - | - | - |
| Maximum load on roof/carrier [kg] | - | - | - | - | - | - |
| Boot volume [l] | 280 | 280 | 280 | 280 | 280 | 280 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | - | - | - | - |
| Boot length [mm] | 1013 | 1013 | 1013 | 1013 | 1013 | 1013 |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | 1000/- | 1000/- | 1000/- | 1000/- | 1000/- | 1000/- |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | 810 | 810 | 810 | 810 | 800 | 810 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | 945/- | 945/- | 945/- | 945/- | 945/- | 945/- |
| Number of doors | 2 | 2 | 2 | 2 | 2 | 2 |
| Number of seats | 2 | 2 | 2 | 2 | 2 | 2 |
| Fuel tank volume [l] | 50 | 50 | 50 | 55 | 55 | 55 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | 0,32 | - | 0,33 | 0,35 |
| Front suspension | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser |
| Rear suspension | four-link | four-link | four-link | four-link | four-link | four-link, stabiliser bar |
| Tyre dimensions front | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 | 245/40 R18 93 Y | 245/35 R19 93 Y XL |
| Tyre dimensions rear | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 94W | 225/50 R17 | 245/40 R18 93 Y | 245/35 R19 93 Y XL |
| Wheel size front | 8,0J x 17 | 8,0J x 17 | 8,0J x 17 | 8,0J x 17 | 8,5J x 15 | 9,0J x 19 |
| Wheel size rear | 8,0J x 17 | 8,0J x 17 | 8,0J x 17 | 8,0J x 17 | 8,5J x 15 | 9,0J x 19 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering | Electro-mechanical variable effect power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 11,0/- | 11,0/- | 11,0/- | 11,0/- | 11,0/- | 11,0/- |
| Overall length [mm] | 4191 | 4191 | 4191 | 4191 | 4199 | 4201 |
| Overall width without/including mirrors [mm] | 1832/1966 | 1832/1966 | 1832/1966 | 1832/1966 | 1832/1966 | 1832/1966 |
| Overall height [mm] | 1355 | 1355 | 1355 | 1355 | 1345 | 1355 |
| Wheelbase [mm] | 2505 | 2505 | 2505 | 2505 | 2505 | 2505 |
| Front wheel track [mm] | 1572 | 1572 | 1572 | 1572 | 1574 | 1564 |
| Rear wheel track [mm] | 1552 | 1552 | 1552 | 1552 | 1553 | 1543 |
| Forward overhang [mm] | 893 | 893 | 893 | 893 | 890 | 893 |
| Rear overhang [mm] | 793 | 793 | 793 | 793 | 804 | 803 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | 14,7 | - | 13,9 | - |
| Approach angle rear [°] | - | - | 12,2 | - | 11,5 | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 986 | 986 | 986 | 986 | 986 | 986 |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | 1450/1362 | 1450/1362 | 1450/1362 | 1450/1362 | 1450/1362 | 1450/1362 |
| Rear elbow/shoulder width [mm] | - | - | - | - | - | - |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
