Audi Q7
Date of manufacture
2009 – 2014 (SUV)
Platform
Volkswagen Group PL71 platform
Manufacturing locations
Bratislava, Slovakia
Designer
Walter de'Silva
Satoshi Wada
Tags
Large SUV
German cars
The Audi Q7 is a luxury SUV produced since 2009 in the Slovakian factory. The vehicle is built on the Volkswagen Group PL71 platform and offers a wide range of petrol and diesel engines. The most powerful model is the 6.0 V12 TDI with a maximum power of 368 kW, which reaches a top speed of 250 km/h and accelerates from 0-100 km/h in 5.5 seconds. The most economical engine, the 3.0 TDI, has a fuel consumption of 7.2 l/100 km and emissions of 189 g/km. The luggage compartment has a volume of 775 liters.
Car body style
SUV
after upgrade (facelift)
Date of manufacture
2009 – 2014Internal designation
4L Technical data
SUV
| 3.0 TFSI | 3.6 FSI | 3.0 TFSI | 4.2 FSI | 3.0 TDI | 3.0 TDI | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Petrol | Ignition supercharged | Petrol | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 6/24 | 6/24 | 6/24 | 8/32 | 6/24 | 6/24 |
| Engine displacement [cm³] | 2995 | 3597 | 2995 | 4163 | 2967 | 2967 |
| Maximum output / speed [kW/min-1] | 200/4750-6500 | 206/6200 | 245/5500-6500 | 257/6800 | 150/3200-4400 | 176/4000-4400 |
| Maximum torque [Nm/min-1] | 400/2250-4750 | 360/2500-5000 | 440/2900-5300 | 440/3500 | 450/1250-2750 | 550/2000-2250 |
| Bore and stroke [mm x mm] | 84,5 x 89,1 | 89,0 x 96,4 | 84,5 x 89,1 | 84,5 x 92,8 | 83,0 x 91,4 | 83,0 x 91,4 |
| Compression ratio | - | - | - | - | - | - |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 8 gear automatic | 6 gear automatic | 8 gear automatic | 6 gear automatic | 8 gear automatic | 6 gear automatic |
| Drive specifications |
|
|
|
|
|
|
| Top speed [km/h] | 222 | 225 | 243 | 244 | 202 | 210 |
| Acceleration 0–100 km/h [s] | 7.9 | 8.5 | 6.9 | 7.4 | 9.1 | 8.5 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 14.4 | 16.9 | 14.4 | 17.5 | 8.2 | 11.3 |
| Out of town [l] | 8.5 | 9.3 | 8.5 | 9.9 | 6.5 | 7.8 |
| Combined [l] | 10.7 | 12.1 | 10.7 | 12.7 | 7.2 | 9.1 |
| CO2 emissions [g/km] | 249 | 289 | 249 | 304 | 189 | 239 |
| Emission standard | EU5 | EU4 | EU5 | EU4 | EU5 | EU4 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 2295 [2325 seven seats] | 2280 [2310 seven seats] | 2315 [2345 seven seats] | 2315 [2335 seven seats] | 2345 [2375 seven seats] | 2370 [2400 seven seats] |
| Overall weight [kg] | 2945 [3075 seven seats] | 2930 [3060 seven seats] | 2965 [3095 seven seats] | 2965 [3095 seven seats] | 2995 [3125 seven seats] | 3020 [3150 seven seats] |
| Maximum trailer weight unbraked/braked [kg] | 750/3500 [750/3200 seven seats] | 750/3500 [750/3200 seven seats] | 750/3500 [750/3200 seven seats] | 750/3500 [750/3200 seven seats] | 750/3500 [750/3200 seven seats] | 750/3500 [750/3200 seven seats] |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | 140 [130 seven seats] | 140 [130 seven seats] | 140 [130 seven seats] | 140 [130 seven seats] | 140 [130 seven seats] | 140 [130 seven seats] |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 775 | 775 | 775 | 775 | 775 | 775 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/2035 | -/2035 | -/2035 | -/2035 | -/2035 | -/2035 |
| Boot volume, third row of seats [l] | - | - | - | - | - | - |
| Boot volume, third row seats folded [l] | - | - | - | - | - | - |
| Boot length [mm] | 1201 | 1201 | 1201 | 1201 | 1201 | 1201 |
| Boot length with rear seats folded [mm] | 2026 | 2026 | 2026 | 2026 | 2026 | 2026 |
| Boot width between wheels/max [mm] | -/1159 | -/1159 | -/1159 | -/1159 | -/1159 | -/1159 |
| Boot height to headliner/ceiling [mm] | -/789 | -/789 | -/789 | -/789 | -/789 | -/789 |
| Loading edge height [mm] | 836 | 836 | 836 | 836 | 836 | 836 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | 1221/- | 1221/- | 1221/- | 1221/- | 1221/- | 1221/- |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 4-7 | 4-7 | 4-7 | 4-7 | 4-7 | 4-7 |
| Fuel tank volume [l] | 100 | 100 | 100 | 100 | 100 | 100 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | double wishbone with stabiliser | double wishbone with stabiliser | double wishbone with stabiliser | double wishbone with stabiliser | double wishbone with stabiliser | double wishbone with stabiliser |
| Rear suspension | double wishbone with stabiliser | double wishbone with stabiliser | double wishbone with stabiliser | double wishbone with stabiliser | double wishbone with stabiliser | double wishbone with stabiliser |
| Tyre dimensions front | 235/60 R18 | 235/60 R18 | 235/60 R18 | 255/55 R18 | 235/60 R18 | 235/60 R18 |
| Tyre dimensions rear | 235/60 R18 | 235/60 R18 | 235/60 R18 | 255/55 R18 | 235/60 R18 | 235/60 R18 |
| Wheel size front | 7.5 J x 18 | 7.5 J x 18 | 7.5 J x 18 | 8 J x 18 | 7.5 J x 18 | 7.5 J x 18 |
| Wheel size rear | 7.5 J x 18 | 7.5 J x 18 | 7.5 J x 18 | 8 J x 18 | 7.5 J x 18 | 7.5 J x 18 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Rack & pinion with variable effect hydraulic power steering | Rack & pinion with variable effect hydraulic power steering | Rack & pinion with variable effect hydraulic power steering | Rack & pinion with variable effect hydraulic power steering | Rack & pinion with variable effect hydraulic power steering | Rack & pinion with variable effect hydraulic power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 12,0/- | 12,0/- | 12,0/- | 12,0/- | 12,0/- | 12,0/- |
| Overall length [mm] | 5089 | 5089 | 5089 | 5089 | 5089 | 5089 |
| Overall width without/including mirrors [mm] | 1983/2177 | 1983/2177 | 1983/2177 | 1983/2177 | 1983/2177 | 1983/2177 |
| Overall height [mm] | 1737 | 1737 | 1737 | 1737 | 1737 | 1737 |
| Wheelbase [mm] | 3002 | 3002 | 3002 | 3002 | 3002 | 3002 |
| Front wheel track [mm] | 1651 | 1651 | 1651 | 1651 | 1651 | 1651 |
| Rear wheel track [mm] | 1681 | 1681 | 1681 | 1681 | 1681 | 1681 |
| Forward overhang [mm] | 962 | 962 | 962 | 962 | 962 | 962 |
| Rear overhang [mm] | 1125 | 1125 | 1125 | 1125 | 1125 | 1125 |
| Clearance [mm] | 205 | 205 | 205 | 205 | 205 | 205 |
| Wading depth [mm] | 500 | 500 | 500 | 500 | 500 | 500 |
| Approach angle front [°] | 21 | 21 | 21 | 21 | 21 | 21 |
| Approach angle rear [°] | 23.4 | 23.4 | 23.4 | 23.4 | 23.4 | 23.4 |
| Transition angle [°] | 21.1 | 21.1 | 21.1 | 21.1 | 21.1 | 21.1 |
| Climbing rate [°] | 60 | 60 | 60 | 60 | 60 | 60 |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1030 | 1030 | 1030 | 1030 | 1030 | 1030 |
| Headroom rear [mm] | 990 | 990 | 990 | 990 | 990 | 990 |
| Front elbow/shoulder width [mm] | 1490/- | 1490/- | 1490/- | 1490/- | 1490/- | 1490/- |
| Rear elbow/shoulder width [mm] | 1475/- | 1475/- | 1475/- | 1475/- | 1475/- | 1475/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| Third row of seats, headroom [mm] | 904 | 904 | 904 | 904 | 904 | 904 |
| Third row elbow/shoulder width [mm] | 1159 | 1159 | 1159 | 1159 | 1159 | 1159 |
| 3.0 TDI | 3.0 TDI clean diesel | 3.0 TDI clean diesel | 4.2 TDI | 4.2 TDI | 6.0 V12 TDI | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 6/24 | 6/24 | 6/24 | 8/32 | 8/32 | 12/48 |
| Engine displacement [cm³] | 2967 | 2967 | 2967 | 4134 | 4134 | 5934 |
| Maximum output / speed [kW/min-1] | 176/3800-4400 | 176/4000-4400 | 176/4000-4400 | 250/4000 | 250/4000 | 368/3750 |
| Maximum torque [Nm/min-1] | 550/1750-2500 | 550/2000-2250 | 550/2000-2250 | 760/1750-3000 | 800/1750-2750 | 1000/1750-3250 |
| Bore and stroke [mm x mm] | 83,0 x 91,4 | 83,0 x 91,4 | 83,0 x 91,4 | 83,0 x 95,5 | 83,0 x 95,5 | 83,0 x 91,4 |
| Compression ratio | - | - | - | - | - | - |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 | 4x4 |
| Gearbox | 8 gear automatic | 6 gear automatic | 8 gear automatic | 6 gear automatic | 8 gear automatic | 6 gear automatic |
| Drive specifications |
|
|
|
|
|
|
| Top speed [km/h] | 215 | 210 | 215 | 240 | 242 | 250 |
| Acceleration 0–100 km/h [s] | 7.9 | 8.5 | 8.1 | 6.4 | 6.4 | 5.5 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 8.6 | 11.2 | 10.9 | 12.8 | 12.0 | 14.8 |
| Out of town [l] | 6.7 | 7.6 | 6.9 | 8.2 | 7.6 | 9.3 |
| Combined [l] | 7.4 | 8.9 | 8.4 | 9.9 | 9.2 | 11.3 |
| CO2 emissions [g/km] | 195 | 234 | 219 | 262 | 242 | 298 |
| Emission standard | EU5 | EU6 | EU6 | EU4 | EU5 | EU5 |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 2345 [2375 seven seats] | 2420 [2450 seven seats] | 2410 [2440 seven seats] | 2495 [2525 seven seats] | 2485 [2515 seven seats] | 2710 |
| Overall weight [kg] | 2995 [3125 seven seats] | 3070 [3200 seven seats] | 3060 [3190 seven seats] | 3145 [3275 seven seats] | 3135 [3265 seven seats] | 3405 |
| Maximum trailer weight unbraked/braked [kg] | 750/3500 [750/3200 seven seats] | 750/3500 [750/3200 seven seats] | 750/3500 [750/3200 seven seats] | 750/3500 [750/3200 seven seats] | 750/3500 [750/3200 seven seats] | 750/3300 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | 140 [130 seven seats] | 140 [130 seven seats] | 140 [130 seven seats] | 140 [130 seven seats] | 140 [130 seven seats] | 140 [130 seven seats] |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 100/- | 100/- | 100/- | 100/- |
| Boot volume [l] | 775 | 775 | 775 | 775 | 775 | 775 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/2035 | -/2035 | -/2035 | -/2035 | -/2035 | -/2035 |
| Boot volume, third row of seats [l] | - | - | - | - | - | - |
| Boot volume, third row seats folded [l] | - | - | - | - | - | - |
| Boot length [mm] | 1201 | 1201 | 1201 | 1201 | 1201 | 1201 |
| Boot length with rear seats folded [mm] | 2026 | 2026 | 2026 | 2026 | 2026 | 2026 |
| Boot width between wheels/max [mm] | -/1159 | -/1159 | -/1159 | -/1159 | -/1159 | -/1159 |
| Boot height to headliner/ceiling [mm] | -/789 | -/789 | -/789 | -/789 | -/789 | -/789 |
| Loading edge height [mm] | 836 | 836 | 836 | 836 | 836 | 836 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | 1221/- | 1221/- | 1221/- | 1221/- | 1221/- | 1221/- |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 4-7 | 4-7 | 4-7 | 4-7 | 4-7 | 4-7 |
| Fuel tank volume [l] | 100 | 100 | 100 | 100 | 100 | 100 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | double wishbone with stabiliser | double wishbone with stabiliser | double wishbone with stabiliser | double wishbone with stabiliser | double wishbone with stabiliser | - |
| Rear suspension | double wishbone with stabiliser | double wishbone with stabiliser | double wishbone with stabiliser | double wishbone with stabiliser | double wishbone with stabiliser | - |
| Tyre dimensions front | 235/60 R18 | 235/60 R18 | 235/60 R18 | 255/55 R18 | 255/55 R18 | 295/40 R20 |
| Tyre dimensions rear | 235/60 R18 | 235/60 R18 | 235/60 R18 | 255/55 R18 | 255/55 R18 | 295/40 R20 |
| Wheel size front | 7.5 J x 18 | 7.5 J x 18 | 7.5 J x 18 | 8 J x 18 | 8 J x 18 | 10 J x 20 |
| Wheel size rear | 7.5 J x 18 | 7.5 J x 18 | 7.5 J x 18 | 8 J x 18 | 8 J x 18 | 10 J x 20 |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | Rack & pinion with variable effect hydraulic power steering | Rack & pinion with variable effect hydraulic power steering | Rack & pinion with variable effect hydraulic power steering | Rack & pinion with variable effect hydraulic power steering | Rack & pinion with variable effect hydraulic power steering | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 12,0/- | 12,0/- | 12,0/- | 12,0/- | 12,0/- | 12,0/- |
| Overall length [mm] | 5089 | 5089 | 5089 | 5089 | 5089 | 5063 |
| Overall width without/including mirrors [mm] | 1983/2177 | 1983/2177 | 1983/2177 | 1983/2177 | 1983/2177 | 2000/- |
| Overall height [mm] | 1737 | 1737 | 1737 | 1737 | 1737 | 1737 |
| Wheelbase [mm] | 3002 | 3002 | 3002 | 3002 | 3002 | 3002 |
| Front wheel track [mm] | 1651 | 1651 | 1651 | 1651 | 1651 | 1669 |
| Rear wheel track [mm] | 1681 | 1681 | 1681 | 1681 | 1681 | 1697 |
| Forward overhang [mm] | 962 | 962 | 962 | 962 | 962 | 962 |
| Rear overhang [mm] | 1125 | 1125 | 1125 | 1125 | 1125 | 1125 |
| Clearance [mm] | 205 | 205 | 205 | 240 | 240 | 240 |
| Wading depth [mm] | 500 | 500 | 500 | 535 | 535 | 535 |
| Approach angle front [°] | 21 | 21 | 21 | 23.5 | 23.5 | 23.5 |
| Approach angle rear [°] | 23.4 | 23.4 | 23.4 | 25.4 | 25.4 | 25.4 |
| Transition angle [°] | 21.1 | 21.1 | 21.1 | 23.8 | 23.8 | 23.8 |
| Climbing rate [°] | 60 | 60 | 60 | 60 | 60 | 60 |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1030 | 1030 | 1030 | 1030 | 1030 | 1030 |
| Headroom rear [mm] | 990 | 990 | 990 | 990 | 990 | 990 |
| Front elbow/shoulder width [mm] | 1490/- | 1490/- | 1490/- | 1490/- | 1490/- | 1490/- |
| Rear elbow/shoulder width [mm] | 1475/- | 1475/- | 1475/- | 1475/- | 1475/- | 1475/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| Third row of seats, headroom [mm] | 904 | 904 | 904 | 904 | 904 | 904 |
| Third row elbow/shoulder width [mm] | 1159 | 1159 | 1159 | 1159 | 1159 | 1159 |
