Audi Q7

Date of manufacture

3/2006 – 2009 (SUV)

Platform

Volkswagen Group PL71 platform

Manufacturing locations

Bratislava, Slovakia

Designer

Walter de'Silva

Satoshi Wada

Car body style

SUV

Date of manufacture

3/2006 – 2009

Internal designation

Engine size

Petrol

Diesel

Euro NCAP

Technical data

SUV

	3.6 FSI	4.2 FSI	3.0 TDI	4.2 TDI	V12 TDI
Date of sale	-	-	-	-	-
Engine type	Petrol	Petrol	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	6/24	8/32	6/24	8/16	12/48
Engine displacement [cm³]	3597	4163	2967	4134	5934
Maximum output / speed [kW/min-1]	206/6200	257/6800	176/4000-4400	240/3750	368/3750
Maximum torque [Nm/min-1]	360/2500-5000	440/3500	550/2000-2250	760/1800-2500	1000/1750-3250
Bore and stroke [mm x mm]	89,0 x 96,4	84,5 x 92,8	83,0 x 91,4	83,0 x 95,5	83,0 x 91,4
Compression ratio	-	-	-	-	-
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	direct injection FSI variable valve timing	direct injection FSI variable valve timing	direct injection Common Rail turbo-supercharged particulate filter	direct injection Common Rail supercharging by twin turbochargers particulate filter	direct injection Common Rail supercharging by twin turbochargers particulate filter from 2008 to

Drive axle	4x4	4x4	4x4	4x4	4x4
Gearbox	6 gear automatic	6 gear automatic	6 gear automatic	6 gear automatic	6 gear automatic
Drive specifications	permanent all-wheel drive quattro automatic gearbox tiptronic	permanent all-wheel drive quattro automatic gearbox tiptronic	permanent all-wheel drive quattro automatic gearbox tiptronic	permanent all-wheel drive quattro automatic gearbox tiptronic	permanent all-wheel drive quattro automatic gearbox tiptronic

Top speed [km/h]	225	244	210	236	250
Acceleration 0–100 km/h [s]	8.5	7.4	8.5	6.4	5.5
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	17.8	19.1	11.3	14.9	14.8
Out of town [l]	9.8	10.0	7.8	8.9	9.3
Combined [l]	12.7	13.3	9.1	11.1	11.3
CO2 emissions [g/km]	304	317	239	294	298

Emission standard	EU4	EU4	EU4	EU4	EU4
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

Standby weight [kg]	2205	2240	2295	2420	2605
Overall weight [kg]	2900	2935	2990	3115	3275
Maximum trailer weight unbraked/braked [kg]	-	-	-	-	-
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-

Boot volume [l]	775	775	775	775	775
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/2035	-/2035	-/2035	-/2035	-/2035
Boot volume, third row of seats [l]	-	-	-	-	-
Boot volume, third row seats folded [l]	-	-	-	-	-
Boot length [mm]	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	5	5	5	5	5
Number of seats	4-7	4-7	4-7	4-7	4-7
Fuel tank volume [l]	75	75	100	100	100
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-
Front suspension	-	-	-	-	-
Rear suspension	-	-	-	-	-
Tyre dimensions front	235/60 R18	255/55 R18	235/60 R18	255/55 R18	295/40 R20
Tyre dimensions rear	235/60 R18	255/55 R18	235/60 R18	255/55 R18	295/40 R20
Wheel size front	-	-	-	-	-
Wheel size rear	-	-	-	-	-
Brake dimensions front	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-
Steering	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	-	-	-	-	-

Overall length [mm]	5086	5086	5086	5086	5063
Overall width without/including mirrors [mm]	1983/-	1983/-	1983/-	1983/-	2000/-
Overall height [mm]	1737	1737	1737	1737	1737
Wheelbase [mm]	3002	3002	3002	3002	3002
Front wheel track [mm]	1651	1651	1651	1651	1651
Rear wheel track [mm]	1676	1676	1676	1676	1676
Forward overhang [mm]	-	-	-	-	-
Rear overhang [mm]	-	-	-	-	-
Clearance [mm]	205	205	205	240	240
Wading depth [mm]	500	500	500	535	535
Approach angle front [°]	21.9	21.9	21.9	-	-
Approach angle rear [°]	23.4	23.4	23.4	-	-
Transition angle [°]	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-

Headroom front [mm]	1003	1003	1003	1003	1003
Headroom rear [mm]	990	990	990	990	990
Front elbow/shoulder width [mm]	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-
Third row of seats, headroom [mm]	904	904	904	904	904
Third row elbow/shoulder width [mm]	-	-	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
