Audi Q5

Date of manufacture

2008 – 2012 (SUV)

Platform

MLB/MLP

Manufacturing locations

Ingolstadt, Germany

Designer

Christian Winkelmann

Car body style

SUV

Date of manufacture

2008 – 2012

Internal designation

Engine size

Petrol

2.0 TFSI 132 kW quattro

2.0 TFSI 155 kW quattro

3.2 FSI 199 kW quattro

Diesel

2.0 TDI 105 kW quattro

2.0 TDI 125 kW quattro

3.0 TDI 176 kW quattro

Euro NCAP

Technical data

SUV

	2.0 TFSI 132 kW quattro	2.0 TFSI 155 kW quattro	2.0 TFSI 155 kW quattro	3.2 FSI 199 kW quattro	2.0 TDI 105 kW quattro	2.0 TDI 125 kW quattro
Date of sale	-	-	-	-	-	-
Engine type	Ignition supercharged	Ignition supercharged	Ignition supercharged	Ignition supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	6/24	4/16	4/16
Engine displacement [cm³]	1984	1984	1984	3197	1968	1968
Maximum output / speed [kW/min-1]	132/4000-6000	155/4300-6000	155/4300-6000	199/6500	105/4200	125/4200
Maximum torque [Nm/min-1]	320/1500-3900	350/1500-4200	350/1500-4200	330/3000-5000	320/1750-2500	350/1750-2500
Bore and stroke [mm x mm]	82,5x92,8	82,5x92,8	82,5x92,8	85,5x92,8	81,0 x 95,5	81,0 x 95,5
Compression ratio	9,6:1	9,6:1	9,6:1	12,5:1	16,5:1	16,5:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	direct injection turbo-supercharged variable timing of intake valves Valvelift	direct injection turbo-supercharged variable timing of intake valves Valvelift	direct injection turbo-supercharged variable timing of intake valves Valvelift	direct injection variable valve timing Valvelift	direct injection Common Rail turbocharger with variable blade geometry particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter

Drive axle	4x4	4x4	4x4	4x4	4x4	4x4
Gearbox	6 gear manual	6 gear manual	7 gear automatic	7 gear automatic	6 gear manual	6 gear manual
Drive specifications	permanent all-wheel drive quattro	permanent all-wheel drive quattro	permanent all-wheel drive quattro dual-clutch automatic gearbox S tronic	permanent all-wheel drive quattro dual-clutch automatic gearbox S tronic	permanent all-wheel drive quattro	permanent all-wheel drive quattro

Top speed [km/h]	210	222	222	234	190	204
Acceleration 0–100 km/h [s]	8.5	7.6	7.2	6.9	11.4	9.5
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	10.3	10.3	10.5	12.3	7.2	7.3
Out of town [l]	6.8	6.8	7.5	7.6	5.6	5.6
Combined [l]	8.1	8.1	8.6	9.3	6.2	6.2
CO2 emissions [g/km]	188	188	199	218	162	163

Emission standard	EU5	EU5	EU5	EU5	EU5	EU5
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1795	1795	1830	1880	1830	1830
Overall weight [kg]	2330	2330	2365	2415	2365	2365
Maximum trailer weight unbraked/braked [kg]	750/2000	750/2000	750/2000	750/2000	750/1800	750/1800
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	80	80	80	80	80	80
Maximum load on roof/carrier [kg]	100/-	100/-	100/-	100/-	100/-	100/-

Boot volume [l]	540	540	540	540	540	540
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1560	-/1560	-/1560	-/1560	-/1560	-/1560
Boot length [mm]	926	926	926	926	926	926
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	1050/-	1050/-	1050/-	1050/-	1050/-	1050/-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	693	693	693	693	693	693
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	1079/-	1079/-	1079/-	1079/-	1079/-	1079/-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	75	75	75	75	75	75
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	0.33	0.33	0.33	0.33	0.33	0.33
Front suspension	-	-	-	-	-	-
Rear suspension	-	-	-	-	-	-
Tyre dimensions front	235/65 R17	235/65 R17	235/65 R17	235/60 R18	235/65 R17	235/65 R17
Tyre dimensions rear	235/65 R17	235/65 R17	235/65 R17	235/60 R18	235/65 R17	235/65 R17
Wheel size front	8Jx17	8Jx17	8Jx17	8Jx18	8Jx17	8Jx17
Wheel size rear	8Jx17	8Jx17	8Jx17	8Jx18	8Jx17	8Jx17
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	-	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	11.6	11.6	11.6	11.6	11.6	11.6

Overall length [mm]	4629	4629	4629	4629	4629	4629
Overall width without/including mirrors [mm]	1898/2089	1898/2089	1898/2089	1898/2089	1898/2089	1898/2089
Overall height [mm]	1653	1653	1653	1653	1653	1653
Wheelbase [mm]	2807	2807	2807	2807	2807	2807
Front wheel track [mm]	1617	1617	1617	1617	1617	1617
Rear wheel track [mm]	1613	1613	1613	1613	1613	1613
Forward overhang [mm]	895	895	895	895	895	895
Rear overhang [mm]	927	927	927	927	927	927
Clearance [mm]	200	200	200	200	200	200
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	25	25	25	25	25	25
Approach angle rear [°]	25	25	25	25	25	25
Transition angle [°]	17.6	17.6	17.6	17.6	17.6	17.6
Climbing rate [°]	31	31	31	31	31	31
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	1043	1043	1043	1043	1043	1043
Headroom rear [mm]	990	990	990	990	990	990
Front elbow/shoulder width [mm]	1465/-	1465/-	1465/-	1465/-	1465/-	1465/-
Rear elbow/shoulder width [mm]	1432/-	1432/-	1432/-	1432/-	1432/-	1432/-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	2.0 TDI 125 kW quattro	3.0 TDI 176 kW quattro
Date of sale	-	-
Engine type	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	6/24
Engine displacement [cm³]	1968	2967
Maximum output / speed [kW/min-1]	125/4200	176/4000-4400
Maximum torque [Nm/min-1]	350/1750-2500	500/1500-3000
Bore and stroke [mm x mm]	81,0 x 95,5	83,0x91,4
Compression ratio	16,5:1	16,8:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	direct injection Common Rail turbocharger with variable blade geometry particulate filter	direct injection Common Rail turbocharger with variable blade geometry particulate filter

Drive axle	4x4	4x4
Gearbox	7 gear automatic	7 gear automatic
Drive specifications	permanent all-wheel drive quattro dual-clutch automatic gearbox S tronic	permanent all-wheel drive quattro dual-clutch automatic gearbox S tronic

Top speed [km/h]	200	225
Acceleration 0–100 km/h [s]	9.9	6.5
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	8.8	9.2
Out of town [l]	5.9	6.6
Combined [l]	7.0	7.5
CO2 emissions [g/km]	184	199

Emission standard	EU5	EU5
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1895	1955
Overall weight [kg]	2430	2490
Maximum trailer weight unbraked/braked [kg]	750/2000	750/2000
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	80	80
Maximum load on roof/carrier [kg]	100/-	100/-

Boot volume [l]	540	540
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1560	-/1560
Boot length [mm]	926	926
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	1050/-	1050/-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	693	693
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	1079/-	1079/-

Number of doors	5	5
Number of seats	5	5
Fuel tank volume [l]	75	75
AdBlue tank volume [l]	-	-
Air resistance [Cd]	0.33	0.33
Front suspension	-	-
Rear suspension	-	-
Tyre dimensions front	235/65 R17	235/60 R18
Tyre dimensions rear	235/65 R17	235/60 R18
Wheel size front	8Jx17	8Jx18
Wheel size rear	8Jx17	8Jx18
Brake dimensions front	-	-
Brake dimensions rear	-	-
Steering	-	-
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	11.6	11.6

Overall length [mm]	4629	4629
Overall width without/including mirrors [mm]	1898/2089	1898/2089
Overall height [mm]	1653	1653
Wheelbase [mm]	2807	2807
Front wheel track [mm]	1617	1617
Rear wheel track [mm]	1613	1613
Forward overhang [mm]	895	895
Rear overhang [mm]	927	927
Clearance [mm]	200	200
Wading depth [mm]	-	-
Approach angle front [°]	25	25
Approach angle rear [°]	25	25
Transition angle [°]	17.6	17.6
Climbing rate [°]	31	31
Maximum side tilt [°]	-	-

Headroom front [mm]	1043	1043
Headroom rear [mm]	990	990
Front elbow/shoulder width [mm]	1465/-	1465/-
Rear elbow/shoulder width [mm]	1432/-	1432/-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
