	2,2 JTS	2,2 JTS	1,8 TBi	3,2 V6 JTS	3,2 V6 JTS	3,2 V6 JTS
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Ignition supercharged	Petrol	Petrol	Petrol
Number of cylinders/valves	4/16	4/16	4/16	6/24	6/24	6/24
Engine displacement [cm³]	2198	2198	1742	3195	3195	3195
Maximum output / speed [kW/min-1]	136/6500	136/6500	147/5000	191/6200	191/6200	191/6200
Maximum torque [Nm/min-1]	230/4500	230/4500	320/1400	322/4500	322/4500	322/4500
Bore and stroke [mm x mm]	86,0 x 94,6	86,0 x 94,6	83,0 x 80,5	85,6 x 89,0	85,6 x 89,0	85,6 x 89,0
Compression ratio	11,3:1	11,3:1	9,5:1	11,25:1	11,25:1	11,25:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable valve timing direct injection	variable valve timing direct injection	variable valve timing direct injection turbo-supercharged	variable valve timing direct injection	variable valve timing direct injection	variable valve timing direct injection

Drive axle	Front	Front	Front	Front	4x4	4x4
Gearbox	6 gear manual	6 gear robotic manual	6 gear manual	6 gear manual	6 gear manual	6 gear automatic
Drive specifications	-	six-speed robotic gearbox Selespeed steering wheel paddles for gearbox control	-	-	all-wheel drive Q4 with central differential Torsen C	automatic gearbox Q‐Tronic steering wheel paddles for gearbox control all-wheel drive Q4 with central differential Torsen C

Top speed [km/h]	224	224	235	250	244	244
Acceleration 0–100 km/h [s]	8.8	8.8	7.8	7.2	7.0	7.2
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	12.8	12.6	11.9	16.5	16.9	18.4
Out of town [l]	7.1	7.1	6.1	7.9	8.4	8.6
Combined [l]	9.2	9.1	8.2	11.1	11.5	12.2
CO2 emissions [g/km]	218	214	192	262	272	288

Emission standard	EU4	EU4	EU5	EU4	EU4	EU4
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1505	1505	1490	1600	1665	1685
Overall weight [kg]	-	-	1840	1950	2015	2035
Maximum trailer weight unbraked/braked [kg]	-/1450	-/1450	-/1450	-/1500	-/1500	-/1500
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	253	253	253	253	253	253
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-	-	-
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	2	2	2	2	2	2
Number of seats	2	2	2	2	2	2
Fuel tank volume [l]	70	70	70	70	70	70
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	four-link	four-link	four-link	four-link	four-link	four-link
Rear suspension	multilink	multilink	multilink	multilink	multilink	multilink
Tyre dimensions front	225/50 R17	225/50 R17	225/50 R17	225/50 R17	225/50 R17	225/50 R17
Tyre dimensions rear	225/50 R17	225/50 R17	225/50 R17	225/50 R17	225/50 R17	225/50 R17
Wheel size front	7.5Jx17	7.5Jx17	7.5Jx17	7.5Jx17	7.5Jx17	7.5Jx17
Wheel size rear	7.5Jx17	7.5Jx17	7.5Jx17	7.5Jx17	7.5Jx17	7.5Jx17
Brake dimensions front	305x28	305x28	330x28	330x28	330x28	330x28
Brake dimensions rear	278x12	278x12	292x12	292x22	292x22	292x22
Steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.7	10.7	10.7	10.7	10.7	10.7

Overall length [mm]	4393	4393	4393	4393	4393	4393
Overall width without/including mirrors [mm]	1830/-	1830/-	1830/-	1830/-	1830/-	1830/-
Overall height [mm]	1318	1318	1318	1318	1318	1318
Wheelbase [mm]	2528	2528	2528	2528	2528	2528
Front wheel track [mm]	1579	1579	1579	1579	1579	1579
Rear wheel track [mm]	1559	1559	1559	1559	1559	1559
Forward overhang [mm]	1000	1000	1000	1000	1000	1000
Rear overhang [mm]	865	865	865	865	865	865
Clearance [mm]	-	-	-	-	-	-
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	2,0 JTD	2,4 JTD	2,4 JTD
Date of sale	-	-	-
Engine type	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	5/20	5/20
Engine displacement [cm³]	1956	2387	2387
Maximum output / speed [kW/min-1]	125/4000	147/4000	154/4000
Maximum torque [Nm/min-1]	360/1750	400/1500	400/1500
Bore and stroke [mm x mm]	83,0 x 90,4	82,0 x 90,4	82,0 x 90,4
Compression ratio	-	-	-
Oil volume [l]	-	-	-
Coolant volume [l]	-	-	-
Technical specifications	direct injection Common Rail turbo-supercharged	direct injection Common Rail turbo-supercharged	direct injection Common Rail turbo-supercharged

Drive axle	Front	Front	Front
Gearbox	6 gear manual	6 gear automatic	6 gear manual
Drive specifications	-	automatic gearbox Q‐Tronic steering wheel paddles for gearbox control	-

Top speed [km/h]	218	225	231
Acceleration 0–100 km/h [s]	9.0	8.5	8.1
Acceleration 0–80 km/h [s]	-	-	-
Acceleration 80–120 km/h [s]	-	-	-

City [l]	7.1	11.4	9.2
Out of town [l]	4.4	5.8	5.4
Combined [l]	5.4	7.9	6.8
CO2 emissions [g/km]	142	208	179

Emission standard	EU5	EU4	EU4
Standard for fuel consumption measurement	-	-	-
Energy class	-	-	-
Stationary vehicle noise [dB]	-	-	-
Driving noise [dB]	-	-	-

Standby weight [kg]	1540	1655	1635
Overall weight [kg]	1890	2005	1985
Maximum trailer weight unbraked/braked [kg]	-/1500	-/1500	-/1500
Maximum front/rear axle load [kg]	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-
Maximum load on roof/carrier [kg]	-	-	-

Boot volume [l]	253	253	253
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-
Boot length [mm]	-	-	-
Boot length with rear seats folded [mm]	-	-	-
Boot width between wheels/max [mm]	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-
Loading edge height [mm]	-	-	-
Height of the open boot door [mm]	-	-	-
Boot opening height [mm]	-	-	-
Boot opening width min/max [mm]	-	-	-

Number of doors	2	2	2
Number of seats	2	2	2
Fuel tank volume [l]	70	70	70
AdBlue tank volume [l]	-	-	-
Air resistance [Cd]	-	-	-
Front suspension	four-link	four-link	four-link
Rear suspension	multilink	multilink	multilink
Tyre dimensions front	225/50 R17	225/50 R17	225/50 R17
Tyre dimensions rear	225/50 R17	225/50 R17	225/50 R17
Wheel size front	7.5Jx17	7.5Jx17	7.5Jx17
Wheel size rear	7.5Jx17	7.5Jx17	7.5Jx17
Brake dimensions front	330x28	330x28	330x28
Brake dimensions rear	292x22	292x22	292x22
Steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering
Number of steering wheel turns	-	-	-
Turning diameter track/circumference [m]	10.7	10.7	10.7

Overall length [mm]	4393	4393	4393
Overall width without/including mirrors [mm]	1830/-	1830/-	1830/-
Overall height [mm]	1318	1318	1318
Wheelbase [mm]	2528	2528	2528
Front wheel track [mm]	1579	1579	1579
Rear wheel track [mm]	1559	1559	1559
Forward overhang [mm]	1000	1000	1000
Rear overhang [mm]	865	865	865
Clearance [mm]	-	-	-
Wading depth [mm]	-	-	-
Approach angle front [°]	-	-	-
Approach angle rear [°]	-	-	-
Transition angle [°]	-	-	-
Climbing rate [°]	-	-	-
Maximum side tilt [°]	-	-	-

Headroom front [mm]	-	-	-
Headroom rear [mm]	-	-	-
Front elbow/shoulder width [mm]	-	-	-
Rear elbow/shoulder width [mm]	-	-	-
Legroom front knees/total [mm]	-	-	-
Legroom rear knees/total [mm]	-	-	-

Gallery

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
